128 2.54mm pcb mini mini cable 3 way fuse 10a terminal block with awg 28 12
- Category: >>>
- Supplier: Cixi Zhongheng Electronics Co. Ltd.
Share on (1600467725702):
Product Overview
Description
Pitch：2.54MM | ||
Part | Material | Plated |
Frame: | PA66 UL94V-0 | － |
Contact: | Brass | Tin |
Screw: | M1.5Steel | Ni |
Clamp： | Brass | Ni |
Electrical | ||
Voltage: | 150V | |
Current: | 6A | |
Wire size: | 18-30AWG | |
Poles: | 2-30P | |
Insulation Reslistance: | 5000MΩ/1000V | |
Withstand Voltage: | AC2000V/1Min | |
Mechanical | ||
Acceptable Temperation: | -33℃~+120℃ | |
Max Soldering: | +250℃,5Sec | |
Strip Length: | 4.5-5.0mm |
