Product Name :

Video wall controller 4k 3x5 36x36 72x72 Input supports HDMI, DVI, VGA, HDBaseT, IP, SDI, AV, Ypbpr, optical fiber signal

Product Introduction :

This is a series of mixed card intelligent image splicing processor products, which can display multiple dynamic and static pictures on LED or LCD screens of different specifications, and support multi-window, superposition and roaming.

This series of products support a variety of sizes, meeting different sizes of screen-driven display. Support the mixed use of a variety of input and output signal formats, HDMI, DVI, VGA, SDI, HDBaseT and DP signal card can be selected, according to specific need.

The products work with the smart management software enable more screen splicing effects and better satisfy various user needs. It supports OSD, scene management, high-definition wallpaper, scrolling subtitles, upgrade, and realize the presentation of video images or big data with different needs on the spot; supports preview and echo function to achieve visual control management. Optional high performance redundant power supply module, that is, when the other power module failure will not affect the power supply of the equipment, the equipment can still work properly and effectively.

Features :

• Modular design, input cards: 4K HDMI, 4K DP, HDMI, DVI, VGA, SDI, HDBaseT.


• Output cards (up to two input video source at one screen): HDMI, DVI, HDBaseT.


• Output cards (up to four input video source at one screen):HDMI, DVI.


• Support LED and LCD screens.


• Support high-definition multi-port signal input and real-time synchronous output, compatible with Nvidia Mosaic and AMD Eyefinity technology.


• The Custom TV sign quickly traced back to video signal sources.


• Support output resolution selection and video resolution up to 1920x1200@60Hz.


• Support equipment high temperature alarm and intelligent fan regulation.


• Real-time display and preview, to implement visual operation management of equipment.


• Scene recalling, scene saving, scene rotation, getting and setting IP by RS232 communication commands.


• Support scrolling subtitles that be set font, size, color, position, transparent, dynamic and static parameters.


• Output picture supports splicing, segmentation, window superposition, scaling, stretching, cutting, PIP (picture in picture), roaming and so on.


• Up to build 2 or 4 windows on each display screen, single signal source can build many windows.


• Up to 4 groups of output screens can be set, and the video resolution of any group screen can be user-defined.


• Support to upload ultra-high wallpaper.


• Support user rating, decentralized management.


• Scene management: clearing, saving, calling, the rotated scene.


• Support configuration of backup and recovery: backup information, power-off memory.


• Controlled in a variety of ways, including RS232 instruction control and LAN software control, and supports serial port or network port control of third-party devices.


• Arbitrary installation, no need to connect the processor output port to the LED screen sending card in a fixed order.

Signal Card :

    Package List :

l 1x Multi-screen Splicing Processor

l 2x Mounting Ears with 12x Screws

l 2 Handles with 4x Screws

l 4x Plastic Cushions

l 1x RS232 Cable

l 1x Power Cord

l 2x 3-pin pluggable terminal block

l 1x Disk

l 1x Phillips screwdriver

l 1x User Manual
