Cummins diesel engine 6CTAA8.3 C250 cummins 6ct engine new for CRANE
- Category: >>>
- Supplier: Shiyan Qingbang Machinery Equipment Co. Ltd.
Share on (1600467863275):
Product Overview
Description
Small Tips for Quick Service:
If you need assistance with selecting the right replacement parts for your engine, please contact our ONLINE SERVICE to get fast customer support. For us to provide you with the correct information, please have your Cummins Engine Part Number or Engine Serial Number ready, so that we can give you the best price possible along with our expertise.
C 8.3L
Proven technology for reliable power.
Like the B-Series, C-Series engines have established an unrivalled reputation for reliability. Engines in the series incorporate features to reduce maintenance and enhance performance in order to meet the most demanding requirements of generator set operation.
Specification for the C-Series includes everything you would expect from G-Drives B-Series but at 8.3 liters and with a six-cylinder envelope the C-Series delivers greater power at standby, prime and base.
Cummins C8.3 has quietly improved, every year. Dual Ni-Resist piston inserts reduce friction, increase piston life and decrease oil consumption. The combustion chamber bowl, crank angle and helical gear have all been modified to help reduce noise. An in-line fuel pump delivers fuel at higher injection pressures for cleaner combustion, more power and lower emissions. The result is higher torque output from less fuel. And, because you can run a C8.3 on every kind of fuel from Jet-A to kerosene to diesel, it's right at home in the most remote locations.
C8.3 (TIER 2)
Advertised Horsepower 185 - 260 hp, 138 - 194 kW
Peak Torque 631 - 889 lb-ft, 856 - 1205 N•m
Cylinders 6
Oil System Capacity 21 qt, 19.9 liters\t
Certification Tier 2 / Stage II
Application Agriculture, Construction
Length \t44.4 in\t1128 mm
Width \t29.5 in\t749 mm
Height\t 43.2 in\t1096 mm
Weight (wet)\t 1,360 lb\t617 kg
From excavators to cranes to front end loaders, the C8.3 is one of the most versatile engines in every kind of construction equipment. It's also one of the most successful, with millions of C Series engines in use around the globe. Reliable performance with reduced maintenance helps explain its popularity.
Today's C8.3 is available in a wide range of ratings, from 185-260 hp. Heavy-duty standard features like the Holset HX40 turbocharger and pistons with Ni-Resist inserts make every C8.3 last longer, while customized options make every C8.3 work better in every kind of equipment and every kind of climate.
Getting the right combination to match your equipment, operating environment and workloads has never been easier. Cummins Advisor is ready to provide expert assistance with your installation process.
Every C8.3 engine comes with a base warranty.
Proven technology for reliable power.
Like the B-Series, C-Series engines have established an unrivalled reputation for reliability. Engines in the series incorporate features to reduce maintenance and enhance performance in order to meet the most demanding requirements of generator set operation.
Specification for the C-Series includes everything you would expect from G-Drives B-Series but at 8.3 liters and with a six-cylinder envelope the C-Series delivers greater power at standby, prime and base.
Cummins C8.3 has quietly improved, every year. Dual Ni-Resist piston inserts reduce friction, increase piston life and decrease oil consumption. The combustion chamber bowl, crank angle and helical gear have all been modified to help reduce noise. An in-line fuel pump delivers fuel at higher injection pressures for cleaner combustion, more power and lower emissions. The result is higher torque output from less fuel. And, because you can run a C8.3 on every kind of fuel from Jet-A to kerosene to diesel, it's right at home in the most remote locations.
C8.3 (TIER 2)
Advertised Horsepower 185 - 260 hp, 138 - 194 kW
Peak Torque 631 - 889 lb-ft, 856 - 1205 N•m
Cylinders 6
Oil System Capacity 21 qt, 19.9 liters\t
Certification Tier 2 / Stage II
Application Agriculture, Construction
Length \t44.4 in\t1128 mm
Width \t29.5 in\t749 mm
Height\t 43.2 in\t1096 mm
Weight (wet)\t 1,360 lb\t617 kg
From excavators to cranes to front end loaders, the C8.3 is one of the most versatile engines in every kind of construction equipment. It's also one of the most successful, with millions of C Series engines in use around the globe. Reliable performance with reduced maintenance helps explain its popularity.
Today's C8.3 is available in a wide range of ratings, from 185-260 hp. Heavy-duty standard features like the Holset HX40 turbocharger and pistons with Ni-Resist inserts make every C8.3 last longer, while customized options make every C8.3 work better in every kind of equipment and every kind of climate.
Getting the right combination to match your equipment, operating environment and workloads has never been easier. Cummins Advisor is ready to provide expert assistance with your installation process.
Every C8.3 engine comes with a base warranty.
Cummins diesel engine 6CTAA8.3-C250 cummins 6ct engine new for CRANE
FEATURES AT A GLANCE
Cummins diesel engine
6CTAA8.3-C250
cummins 6ct engine new
for CRANE
Model | Rated Powder/ output (HP/KW @RPM) | Peak Torque (NM@RPM) |
6CTA8.3-C205 | 202HP/151KW@1850 | 900@1400 |
6CTA8.3-C215 | 215HP/160KW@2200 | 908@1500 |
6CTA8.3-C230 | 231HP/172KW@2200 | 1000@1500 |
6CTA8.3-C240 | 240HP/179KW@2200 | 1028@1500 |
6CTA8.3-C260 | 260HP/194KW@2200 | 1135@1500 |
PRODUCT SPECIFICATIONS
No | Item | Data |
1 | Engine Model | 6CTAA8.3-C250 engine assembly |
2 | Displacement | 8.3L |
4 | Cylinder | 6 cylinders |
5 | Valve | 24 valves |
6 | Cold Style | Water- cooled |
7 | Start | Electric Start |
8 | Maximum Power (HP/KW) | 235/ 175 |
9 | Type | Inline 6 cylinders, water-cooled, four strokes |
10 | Bore x Stroke(MM) | 114*135 |
11 | Aspiration | charged, inter-cooled |
12 | Rated speed (rpm) | 1800 |
Cummins Engines Range List
ONE STOP CUMMINS SHOP
Shiyan Qingbang Machinery Equipment Co., ltd is your one-stop shop for a complete range of Cummins Engine Assemblies and Cummins parts.
No matter the size or diversity of your fleet, we have parts for Cummins diesel engines that range from the popular B series to the Big Cam and everything in between.
Keeping business moving efficiently and dependably is the name of the game and Cummins is among the best.
1 YEAR WARRANTY aftersales service, FREE SHIPPING on Cummins spare parts.
Cummins QuickServe Online Tips
For us to provide you with the correct information, please have your Cummins Engine Part Number or Engine Serial Number ready, so that we can give you the best price possible along with our expertise.
Qingbang Profile
ONE-STOP CUMMINS SHOP
Shiyan Qingbang Machinery Equipment Co., Ltd. is specialized in the trade and service of Cummins engine assembly and Cummins spare parts, with deep study at Cummins machinery engines like 4BT, 6BT, 6CT, L8.9, M11, X15, K19 series, electronic control engines like ISB, ISD, ISC, ISL, ISM, ISX, QSB, QSC, QSL, QSM, QSK, QSX series and mining and marine engines like NT855, K19, K38, K50, QSK18, QSK38, QSK60, series.
We provide customers with professional, fast and effective services based on the service concept of “quality first and reputation
priority”.
priority”.
Cummins Packaging and Shipping
Packing and Shipping
1, International Express. Such as DHL,UPS,EMS,ARAMEX and so on. Usually you can receive the packages within 5-7 days after shipping.
2, Air Transportation. For goods above 100kg, it is a economical choice for the customers.
3,International Marine Container, FCL / LCL.
4,We will send the goods as fast as we can to save your time.
2, Air Transportation. For goods above 100kg, it is a economical choice for the customers.
3,International Marine Container, FCL / LCL.
4,We will send the goods as fast as we can to save your time.
Why Choose Us
CHOOSE US, SAVE MOST
Leave the trouble to ourselves
&
Bring the simplicity to customers.
As an honest, helpful, professional partners of our esteemed customers, we are aiming at buliding long term business relationship
by providing genuine motor diesel parts and professional service.
We declare seriously that we won't offer any FAKE, COPY, BAD QUALITY parts to cause our customers in trouble!
FAQ
Q1: What is the parts packing?
A: All the packages are genuine original packing, we can also provide neutral packing or according to your requirements.
Q2: What is your payment Terms?
A: We accept T/T, Western Union, Alibaba Trade Assurance Payment Order, and Paypal. T/T and Alibaba Trade Assurance Order Payment always need 2-3 workdays to our accounts. Western Union and Paypal will be in time to our account.
Q3: What is your transport method?
A: Courier Express, By air, By sea, By truck.
Q4: What is your delivery time?
A: We ship goods AT ONCE after receiving your payment if we have products in stock.
If we need time to order products, we will inform the approximate time and ship ASAP.
Q5: When can we receive the goods?
A: It often takes 5-7 days by courier express after receiving your payment, but the actual time depends on the shipping method you choose.
A: All the packages are genuine original packing, we can also provide neutral packing or according to your requirements.
Q2: What is your payment Terms?
A: We accept T/T, Western Union, Alibaba Trade Assurance Payment Order, and Paypal. T/T and Alibaba Trade Assurance Order Payment always need 2-3 workdays to our accounts. Western Union and Paypal will be in time to our account.
Q3: What is your transport method?
A: Courier Express, By air, By sea, By truck.
Q4: What is your delivery time?
A: We ship goods AT ONCE after receiving your payment if we have products in stock.
If we need time to order products, we will inform the approximate time and ship ASAP.
Q5: When can we receive the goods?
A: It often takes 5-7 days by courier express after receiving your payment, but the actual time depends on the shipping method you choose.
