Automatic Gate Opener Electric Lock
US $110.00-$156.00
Factory Direct Sales Aayee Heavy Duty Ac 2000Kg Electric Motors For Sliding Gates For Industrial Use With 1 Year Warranty
- Category: >>>
- Supplier: Hangzhou Aayee Technology Co. Ltd.
Share on (1600468441538):
Product Overview
Description
Products Description
Aayee AC sliding door motor could be bear 600 to 2000kg gate, and integrate seven advanced features:
1. User-friendliness: Only two wires can connect up to 7 groups of external devices such as infrared beams, controller buttons and safety devices.
2. Practicality: The battery position and interface are reserved in the motor, and the battery (optional) can be easily installed and connected to the controller.
3. Advanced: equipped with advanced temperature sensor, so that the motor can adapt to various climatic conditions and overheat protection at the same temperature.
The master/auxiliary mode can be selected to achieve full synchronization of the two motors. This means that 2 motors can be used to make a double-leaf sliding door.
4. Intelligence: It has the function of obstacle detection and automatic setting of working hours. If there is a fault, it can conduct self-diagnosis and report an error through the indicator light.
5. Security: The soft start and soft stop function of each operation can be adjusted.
6. Sturdiness: Die-cast motor base and clutch device, easy to open clutch handle.
7. Quiet: geared motor for bearing.
1. User-friendliness: Only two wires can connect up to 7 groups of external devices such as infrared beams, controller buttons and safety devices.
2. Practicality: The battery position and interface are reserved in the motor, and the battery (optional) can be easily installed and connected to the controller.
3. Advanced: equipped with advanced temperature sensor, so that the motor can adapt to various climatic conditions and overheat protection at the same temperature.
The master/auxiliary mode can be selected to achieve full synchronization of the two motors. This means that 2 motors can be used to make a double-leaf sliding door.
4. Intelligence: It has the function of obstacle detection and automatic setting of working hours. If there is a fault, it can conduct self-diagnosis and report an error through the indicator light.
5. Security: The soft start and soft stop function of each operation can be adjusted.
6. Sturdiness: Die-cast motor base and clutch device, easy to open clutch handle.
7. Quiet: geared motor for bearing.
Product Name | AC sliding gate opener |
Specifications | G20 |
Power Supply | 110V/60Hz;220V/50Hz |
Power of Motor | 1200W |
Output torque | 45Nm |
Operating Speed | 12m/min |
Maximum Gate length | 20m |
Shipping Mass of Unit | 15.8kg |
Maximum Gate Mass | 2000kgs |
Details Images
Accessories
Parts List
1.Install backplane*1
2.Bracket*1
3.Expansion screw*4
4.Screw*4
5.Gasket*2
6.Magnet*2
7.Remote control*2
8.Clutch key*2
Optional accessories
Flash lamp Remote control Photocell Gear rack
Wifi controller
This WIFI smart switch controller could be directly connected to the power circuit, use APP to add devices and connect to your
WIFI router, so as to achieve networking and remote control without adding a host.
Anytime, anywhere, mobile phone remote intelligent control , to create your smart life.
WIFI router, so as to achieve networking and remote control without adding a host.
Anytime, anywhere, mobile phone remote intelligent control , to create your smart life.
Sliding Gate Opener Carton Package
Packaging Details: Standard Exporting Packing
Measurement of carton box: 32*25*39 cm
Weight :15.8KG
Measurement of carton box: 32*25*39 cm
Weight :15.8KG
Company Profile
Aayee Tech Group
Our group was established in 2010 and is located near Hangzhou, Shanghai and Ningbo international ports. Easily traffic,perfect supply chain and sufficient spare parts support Aayee Technology to supply Stable quality and perfect service for you. In 2013 Aayee Technology
specialized in sliding gate motors for 3 years, then we extend this business line to swing gate motors,DC24V motors. Now our business production includes sliding gate motors, swing gate opener ,rolling shutter motors, car barrier and solar motor export to all over the world.
specialized in sliding gate motors for 3 years, then we extend this business line to swing gate motors,DC24V motors. Now our business production includes sliding gate motors, swing gate opener ,rolling shutter motors, car barrier and solar motor export to all over the world.
Why Choose Us
We takes the “Quality Is Life” as production standard and principle, executing complete quality assurance system involving the whole process from R&D to manufacture, so our products have enjoyed a good reputation for high quality and low failure rate among our customers.
Sometimes, what they need is very simple–reliable quality, reasonable price, on-time delivery and good service,these are what we can supply.
Contact
Exhibition Participation
Certifications
FAQ
1. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment.
3.What can you buy from us?
Sliding Gate Opener,Swing Gate Opener,Rolling shutter Motor,Boom barrier,Photocell,Transmitter,Flash lamp.
3. Why should you buy from us not from other suppliers?
AAYEE is professional designer and qualified manufacturer of the automatic door control systems.We have sliding/garage/swing/rolling shutter opener and control systems,transmitters,receivers,photocell,flash lamp,keypad etc.
Q4.How can i get a price of needed garage door opener?
A: Please give the exactly size and quantity of your required door. We can give you a detail quotation based on your requirements.
Q5.We want to be your agent of our area. How to apply for this?
A: Please send your ideal and your profile to any e-mails of us .Let's talk more.
Always a pre-production sample before mass production;
Always final Inspection before shipment.
3.What can you buy from us?
Sliding Gate Opener,Swing Gate Opener,Rolling shutter Motor,Boom barrier,Photocell,Transmitter,Flash lamp.
3. Why should you buy from us not from other suppliers?
AAYEE is professional designer and qualified manufacturer of the automatic door control systems.We have sliding/garage/swing/rolling shutter opener and control systems,transmitters,receivers,photocell,flash lamp,keypad etc.
Q4.How can i get a price of needed garage door opener?
A: Please give the exactly size and quantity of your required door. We can give you a detail quotation based on your requirements.
Q5.We want to be your agent of our area. How to apply for this?
A: Please send your ideal and your profile to any e-mails of us .Let's talk more.
