Eddy current dynamometer chassis dyno machine with eddy brake
- Category: >>>
- Supplier: Guangzhou Kingan Auto Parts Co. Limited
Share on (1600469308267):
Product Overview
Description
Eddy current dynamometer chassis dyno machine with eddy brake
Vehicle chassis dynamometer is mainly used for vehicle dynamics property, emissions and
fuel consumption, (used in conjunction with fuel consumption meter, fuel consumption meter etc.) test, can complete car economy experiment, dynamic experiment and reliability
experiment about special experiment and auto transmission system, chassis power output
can be detected, torque, speed, distance, acceleration time, sliding distance and other data.
fuel consumption, (used in conjunction with fuel consumption meter, fuel consumption meter etc.) test, can complete car economy experiment, dynamic experiment and reliability
experiment about special experiment and auto transmission system, chassis power output
can be detected, torque, speed, distance, acceleration time, sliding distance and other data.
Product Description
Model | KDM-3 |
Maximum axle-load (kg) | 3000 |
Maximum absorption power (kw) | 160 |
Tested horse power (hp) | 2000 |
Maximum braking torque (Nm) | 1600 |
Maximum testing speed (km/h) | 130 |
Roller diameter x length (mm) | φ216×1000 |
Center distance (mm) | 480 |
Inside the drum width/width (mm) | 700/2700 工作电压×电流 Working voltage |
Working voltage×current | 96V ×35A |
The power supply | 220V ±10% 50HZ |
