Wylong Full Automatic intelligent smart flute paper cardboard laminator

Share on (1600469330223):


Price:$65,000.00

Quantity:


Product Overview

Description







Features
1,Original paper synchronous dynamic calibration system.
2,Adopt double gap design E type,can pit omtp ise ;a,omatomg paper with a pallet truck.
3,Before send paper type suction a top system ,size conversion from adjustment,easy to operate.
4,Fluff paper receiver system ,can will overlap the finished product, to push again after fluff and tidy,ensure clean paper
5,Electric adjustment,speed and pressure of paper length conversion is convenient
6,PLC computer control system,can automatically detect the status of the operation ,abunormal situation,maintenance and work record.
7,High precision coating system ,automatic liquid level cpntrp;, can according to adjust the volume


Application
Our company specializing in the production of HLK series high precision automatic mouunting machine,used for tissue paper,paper jam,gray paper ,coated paper ,such as joint processing,meet the double-sided printing and laminatingmthin and thick paper laminating special processing requirements,such as high precision of framed ,joint before and after deformation,suitable for wine box,shoebox,tag, elevator,toys,gift boxes,and exquisite packaging products processing,framed the paper smoothness,high accuracy,high hardness,good characteristics.


Specification


model
HLK-1207
HLK-1210
HLK-1410
Max.sheet size
1195*700mm
1195*999mm
1350*995mm
Min.sheet size
450*400mm
450*400mm
450*400mm
power
220/380V 12kw
220/380V 12KW
220/380V 12KW
Thickness of upper paper
120-1000g/㎡
120-1000g/㎡
120-1000g/㎡
Thicness of bottom paper
200-1500g/㎡
200-1500g/㎡
200-1500g/㎡
Laminate Error
±0.5mm
±0.5mm
±0.5mm
Operation space
3*12m
3*12m
3*12m
Max speed
100-150pcs/min
100-150pcs/min
100-150pcs/min
Weight
7000kg
7000kg
7500kg
Dimension
9*1.9*2.2m
9*1.9*2.2m
9*1.9*2.2m


Electric system brand


Name
Original
Brand
main motor
Taiwan
Fukuda
paper feed motor
Taiwan
Li Ming
paper feed motor
Taiwan
Sanya
reducer motor
Taiwan
Fukuda
red light circle
Israel
VOLTA
belt
Japan
UNIENTI
reducer
shanghai
Xinyangda
vacuum pump
Germany
Baker
photoelectric
Japan
Omron
relay
Germany
Schneider
Touch screen
Taiwan
Delta
Inverter
Taiwan
Delta
bearing
Japan
NSK
drive chain
Germany
IWIS
belt tensioner
Taiwan
Taicang Feiting Transmission
The electromagnetic valve
Japan
SMC
Press button
Germany
Schneider
AC contactor
Germany
Schneider
PLC
Taiwan
Delta
Expansion module
Taiwan
Delta


Certifications




Packing and Delivery




Company Profile








Wynlong Machinery Co., Ltd. located in ruian city, is a professional corporation specialize in manufacture full-automatic card mounting machine,full-automatic intelligent high-speed paper mounting machine,one of the full-automatic high-speed turnover paper machine in Zhejiang Province.

With ISO 9001 Certification, advanced technology and equipment as well as the ability of research and development of new products, our products are sold throughout the world and enjoy great popularity both at home and abroad.

Since it was established, our company has followed the principles of "Scientific Management, High Quality and Efficiency", "Customers First, Credibility & Promise." We always take consumers as our first consideration. Persisting in supplying quality products and services,

We sincerely welcome all new and old friends to create a prosperity future.
