Подземный гусеничный гидравлический скальный погрузчик для добычи угля

Подземный гусеничный гидравлический скальный погрузчик для добычи угля

Category: Loaders >>>
Supplier: Shandong,Beijun,Heavy,Industry,Co.,Ltd.

Price:3 000,00 $ - 20 000,00 $

Price in USD:Details

Quantity:

Product Overview

Description

Products Description

Product Paramenters

Model(crawler type)	ZWY-80/37L	ZWY-120/55L
Machine Weight	6500kg	8000kg
Loading Ability	80m³	120m³/h
Digging Width	2800mm	4300mm
Digging Distance	1800mm	2700mm
Digging Height	2100mm	3800mm
Digging Depth	700mm	700mm
Dumping Height	1400-1600	1550-1850mm(can be changed)
Dumping Distance	1500mm(could be raised)	2800mm(can be changed)
Traveling Speed	0.63±5%km/h	0.63km/h
Speed of Scraper Chain	0.5m/s	/
Working pressure	≤20Mpa	≤31.5mpa
Ground clearance	200mm	220mm(variable)
Power	37kw	55kw
Operate mode/Operation Manner	Mechanical pilot	Hydraulic Control
Crawler Inner Width	900mm	1250mm(variable)
Maximum Material Dimension(Width*Height)	650600500	600*650mm
Overall Dimensions during transport	550015501650mm	700020001850mm
Overall Dimensions during operating	700015502000	970020001900mm
Grade ability	≤25º	/
Adaptive Tunnel Fracture(Width*Height)	2*2m	≥3*3m
Adaptive Tunnel Slope	/	≤30º

Model(wheel type)	ZWY-50A	ZWY-60A	ZWY-80A
Traveling Speed	2km	2km	2km/h
Ground Clearance	200mm	200mm	220mm
Wheel Tread	1380mm	1480mm	1700mm
Wheel Base	1500mm	1500mm	1600mm
Rated Working Pressure	16mpa	16mpa	16Mpa
Big Arm Maximum Turning Angle	±73º	±73º	±73º
Total Motor Power	11+4kw	11+4kw	15+4kw
Maximum Material Dimension	650500500mm	600500500	650600500mm
Adaptive Tunnel Gradient	≤15º	≤15º	≤15º
Belt Speed	0.63m/s	0.63m/s	0.63m/s
Overall Dimensions	460013801600mm	520015001600mm	615017501700mm
Machine Weight	3100kg	3400kg	3400kg
Minimum Turning Radius	4m	4m	4.5m
Digging Width	2000mm	2400mm	2400mm
Digging Height	1700mm	1900mm	2100mm
Digging Depth	700mm	700mm	700mm
Digging Distance	1300mm	1550mm	1800mm
Dumping Height	1400-1700mm	1480-1700mm	1700-1900mm
Dumping Distance	1400mm	1400mm	1900(can be raised)
Grade ability	≤15º	≤15º	≤15º
Adaptive Tunnel Minimum Fracture	>1.6*1.8m	1.8*2m	2*2.4m

Application

Packaging & Shipping

Factory workshop

Company Profile

Shandong Beijun Heavy Industry Co., Ltd. is a professional enterprise dedicated to the R&D and manufacturing of mining machinery and construction machinery. The company is located in Jining, Shandong.
It covers an area of 100 acres and has a building area of 20,000 square meters.
The company has large-scale production technology, with an annual production capacity of 4,000 mining trucks, 500 fully hydraulic crawler trucks and 3,000 small excavators.
The company has successively passed ISO9001 quality system certification, EU CE certification and mine safety production qualification. Established a set of ERP information management system for enterprise resource planning, using advanced IT technology to provide the most effective management support for the enterprise.
The company specializes in the production and sales of mining transport vehicles, crawler transport vehicles, small excavators and lawn mower.
The company has a strong technical force, a sound quality assurance system, perfect testing facilities, mature technological processes,
and stable process capabilities, which provide a solid foundation for meeting customer needs and realizing the company's sustainable development.
Beijun people always insist on independent research and development and continuous innovation.
There are currently more than 200 employees, including more than 30 technicians,
40 marketing managers, 15 professors of Mechanical Design.
Over the years, we have been adhering to the business philosophy of "Quality First, Customer First". Beijun Products are exported to African, South American, and Southeast Asian markets.
