Bobbin Battery Primary Lisocl2 Lithium Batteries ER34615 Plus 5A capacitor SPC 1550

Product Overview

Description



SPC 1550,ER34615 bobbin battery,bobbin-type primary lisocl2 lithium batteries

1.Offer High Capacity for A Long Battery Life And High Drain Capability
2.Rapid Flash Re-Cycle Times And An Exceptional Shelf Life

3.High Energy Li-SOCl2 Cylindrical Battery

4.Main Applications:
-Utility Meter (Water, Electricity, Gas, Heat Meter)
-Automatic Meter Reading
-Alarm Or Security System (Smoke Alarm Detector)
-Gps Tracking Systems(Data Logger, Dog Collar, Pir Sensor)
-Real Time Clock
-Automotive Electronics
-Professional Electronics
5.Advantage:
-High And Stable Operating Voltage
-Low Self-Discharge Rate (Less Than 1% Per Year Of Storage At +25°C)
-Wide Range Of Operating Temperature
-Stainless Steel Container And End Caps
-Hermetic Glass-To-Metal Sealing
-Non-Flammable Electrolyte
-Compliant with IEC86-4 Safety Standard, UL, CE, UN.

Product Name	LiSOCl2 Battery ER34615 +SPC 1550
Nominal Voltage	3.6V
Nominal Capacity	19000mAh
Battery Type	High Energy Battery
Max. Constant Current	2000mA
Max.Pulse Current	5000mA (It varies according to the pulse performance (frequency, duration), temperature, battery condition and the minimum voltage acceptable to the applied equipment) Pulse current discharge is provided by SPC1550. The main performance of SPC1550 is as follows: Voltage range 2.5~3.67V Norminal capacity 560As Max. Dimensions φ15.1mm x h 51.0mm Norminal weight About 20g Max. continuous discharge current 2000mA Max. available pulse current 5000mA
Single Cell Dimension	34.2X61.5 mm
Operating Temperature	-40~+85°C
Size	D
Approx. Weight	130g
Shelf Life	More Than 10 Years
Type	Li-SOCl2 Cylindrical Battery
