3L, 5L, 7L, 10L, 15L oxygen generator PSA oxygen concentrator 96% oxygen purity



Product Overviews








Simple usage with a oxygen tank , direct oxygen to pipeline for small hospital or clinic .





Advantage of 15L oxygen generator


(1) The main components are imported to ensure product quality;
(2) The oxygen production process is controlled by microcomputer, fully automatic operation, and the output of oxygen flow is adjustable;
(3) oil-free design, stable concentration, safe and reliable.
(4) Low concentration alarm to ensure oxygen quality.
(5) Using three-phase 380V low-voltage power supply, low noise and low energy consumption.
(6) It can be directly connected to the oxygen supply pipeline system of small medical institutions, which is convenient and flexible to use.
(7) Beautiful appearance, small footprint and less consumables
(8) Integrated oxygen plant system




Model of 15L oxygen generator































































ModelOxygen ProductionMotor Power
(KW)		Size (mm)Weight (KG)Oxygen PurityNoise Level (dB(A))Additional TankMachine Room (m2)
ETO-A20 1Nm3/h (20LPM) 2.50 1600*750*130042093%±3%60±3300L/0.6Mpa10~12
ETO-A30 2Nm3/h (30LPM) 4.00 1600*750*130048093%±3%62±3600L/0.6Mpa10~12
ETO-A50 3Nm3/h (50LPM) 6.00 1600*800*150055093%±3%63±3600L/0.6Mpa12~15
ETO-A80 5Nm3/h (80LPM) 10.00 1600*800*192075093%±3%65±3800L/0.6Mpa12~15

Power Supply:380V/50Hz/3ph    Oxygen Pressure :0.35-0.45Mpa









Why Choose O2 Plant

































































Oxygen SourcesBottled OxygenLiquid OxygenOxygen  Generator
Economy

Repeat purchase, No autonomy


Repeat purchase, No autonomySelf-sufficiency, only power cost
Convenience

Change bottles frequently,


complex to store and operate,


high cost in human source



Transportation with high pressure


tank car,canning, dangerous



Air as raw material,automatically


controlled by controller,


handling safety and convenience


Safety

High pressure, transportation


and storage risk,


explosion problem



Low security, leakage and fire risk,


ultralow temperature problem


(harmful to pipeline\\tank and


harmful body if touch)



High safety, oxygen generated


in normal temperature,


no transportation,


switched off automatically


if fire or earthquake


Cost

One dollar per cube


meter in China


0.7 dollar per cube meter in china0.15 dollar per cube meter in china
Using lifeRepeat purchase

Tank Maintenance in every 2 year


and replace in every 5 year


More than 10 years
Management

human input for carrying,


no modernization management



No intelligent control, oxygen supplied


from natural evaporation,no


modernization management



Intelligent control,


modernization management,


various of alarm protection function


MonitoringNo oxygen monitoring functionNo oxygen monitoring functionOxygen purity monitoring function
Pressure15MP1MP,  -183°C(temperature)≈0.4MP

Installation


requirement


Strictly requirement

30m away from civil architecture,


50m away from public buildings


Only not in basement room
















6_02_016_02_02photobank

6_02_046_02_056_02_06







Quality Control








Our Services


1. Setting trace file for every sold product and survey it quarterly.
2. Providing remote instruction and training for free.
3. Providing on-site services and repairs for free under warranty if problems caused by Eter.
4. Spare parts and on-site services would be provided with best price out of warranty.
5. 7*24 hours online services for free, solution for any problems will be provided within 48 hours.
6. Professional engineer for on-site services will reach within 7 days when needed. (Visa apply should be considered.)








Company Information

company

6_06

6_05




6_03


FAQ


 1. Are you manufacturer or Trade Company?
   We are the manufacturer of 15L oxygen generator , founded in 2003.



 2. What's the order 15L oxygen generator process?
   a. Inquiry---provide us all clear requirements.
   b. Quotation---official quotation form with all clear specifications.
   c. Printing file--- PDF, Ai, CDR, PSD, the picture resolution must be at least 300 dpi.
   d. Contract confirmation---provide correct contract details.
   e. Payment terms--- Negotiable.
   f. Production---mass production
   g. Shipping--- by sea, air or courier. Detailed picture of package will be provided.
   h. Installation and commissioning



3.What terms of payment you use?
   T/T, L/C etc.



4. How to get a prompt quotation of 15L oxygen generator ?
  When you send the inquiry to us, pls kindly send it with below technical information.
  1) O2 flow rate: _____Nm3/hr( or How many cylinders do you want to fill per day(24hours))
  2) O2 purity: _____%
  3) O2 discharge pressure: _____Bar
  4) Voltages and Frequency : ______V/PH/HZ
  5) Application:


  6) Project Location:
