Chinese Factory Price Industrial Empty Stainless Steel Liquid Oxygen Gas Cylinder
- Category: >>>
- Supplier: Hebei Runfeng Low Temperature Equipment Co. Ltd
Share on (1600470343760):
Product Overview
Description
Product Display
Product name | Dewar bottle liquid oxygen bottle dpl450-210-1.37 fish car bottle stores liquid gas |
Size | 516*516*1717mm |
Volume | 210L |
Volume (cubic meters) | 0.210（m3） |
Inner material | Stainless Steel |
Outer material | Stainless Steel |
Design pressure (MPa) | 1.37MPa |
Maximum working pressure (MPa) | 1.37MPa |
Dewars, also known as thermos flasks, are ideal containers and tools for storing liquid gases, cryogenic research and crystal element protection.
The structure of the dewar flask
Case
The inner tank and outer shell of the Dewar are made of stainless steel, and the inner tank support system is made of stainless steel to improve the strength and effectively reduce the heat loss rate.
Cylinder top
In an independent use environment, users can effectively control the use process through discharge valves, booster valves, pressure gauges, liquid phase valves, etc.
Gas cylinder liner
In order to ensure that the inner liner of the gas cylinder is below the safe pressure, a safety valve and a rupture disk are installed on the gas cylinder.
Protective ring
The upper part of each insulated cylinder has a stainless steel ring structure (protection ring) to protect the pipeline. The protection ring is connected to the cylinder by four brackets, and each bracket is slotted to facilitate the use of trolleys and cranes to transport gas cylinders.
The gas cylinder is easy to use, safe, reliable, economical and durable. The specific features are as follows:
1. The support system of the inner tank is made of stainless steel, which can achieve the purpose of low heat loss rate and high strength.
2. It is easy to use and can be operated independently by a single person.
3. Store pure low temperature liquid. The storage gas volume is large. The gas storage capacity of a DP175 Dewar is equivalent to more than 18 times the gas storage capacity of a standard high-pressure gas cylinder.
4. The internal pressure of the gas cylinder will rise during the deactivation stage after being filled with liquid. The gas cylinder has a high-performance adiabatic system, and its pressure rise rate is low. Usually, it is not necessary to reduce the pressure through a safety valve.
5. The built-in supercharger and vaporizer can realize continuous supply of gas or liquid, and no external vaporizer is required under the designed dosage.
The structure of the dewar flask
Case
The inner tank and outer shell of the Dewar are made of stainless steel, and the inner tank support system is made of stainless steel to improve the strength and effectively reduce the heat loss rate.
Cylinder top
In an independent use environment, users can effectively control the use process through discharge valves, booster valves, pressure gauges, liquid phase valves, etc.
Gas cylinder liner
In order to ensure that the inner liner of the gas cylinder is below the safe pressure, a safety valve and a rupture disk are installed on the gas cylinder.
Protective ring
The upper part of each insulated cylinder has a stainless steel ring structure (protection ring) to protect the pipeline. The protection ring is connected to the cylinder by four brackets, and each bracket is slotted to facilitate the use of trolleys and cranes to transport gas cylinders.
The gas cylinder is easy to use, safe, reliable, economical and durable. The specific features are as follows:
1. The support system of the inner tank is made of stainless steel, which can achieve the purpose of low heat loss rate and high strength.
2. It is easy to use and can be operated independently by a single person.
3. Store pure low temperature liquid. The storage gas volume is large. The gas storage capacity of a DP175 Dewar is equivalent to more than 18 times the gas storage capacity of a standard high-pressure gas cylinder.
4. The internal pressure of the gas cylinder will rise during the deactivation stage after being filled with liquid. The gas cylinder has a high-performance adiabatic system, and its pressure rise rate is low. Usually, it is not necessary to reduce the pressure through a safety valve.
5. The built-in supercharger and vaporizer can realize continuous supply of gas or liquid, and no external vaporizer is required under the designed dosage.
