FPV UAV Quadcopter Mini Drone Control Controller PCB Board Assembly Mini Drone Controller PCBA
- Category: >>>
- Supplier: Shenzhen Huaxing Pcba Limited
Share on (1600470474216):
Product Overview
Description
Product Description
Company Profile
Specification
Layer | 1~32 Layers |
Material | FR4,CEM1,CEM3,Hight TG,Rogers,F4B,Taconic,FR1,FR2,94v0,Aluuminum |
Order Quanyity | 1~500,000 |
Board shape | Rectangular,Round,Slots,Cutouts,Complex,Irregular |
Board Cutting | Shear,V-score,Tab-routed,Counter sunk |
Board thickness | 0.2~8.0mm,Flex0.01~0.25“ |
Copper weight | 0.5oZ~12oZ |
Solder mask | Double-sided green LPI,Also support red,white,yellow,blue,black,purple,etc |
Silk screen | Double-sided or single-sided in white,yellow,red,black,or negative |
Min line width/space | 0.06/0.06mm |
Max board dimensions | 25.6 inch*43.3 inch or 650mm*1100mm |
Min drill hole diameter | 0.1mm |
Surface finish | HASL,ENIG,Immission Ti,Immisson Silver,OSp,ENEPIG,etc |
Board thickness tolerance | ±10% |
Minimal slot width | 0.12"，3.0mm，or 120 mils |
V-score depth | 20~25% of board thickness |
PTH Wall Thinckness | >0.025mm |
PTH Hole Dia Tolerance | ±0.076mm |
Non PTH Hole Dia Tolerance | ±0.05mm |
Hole Position Deviation | ±0.076mm |
Sink holes | Yes |
Quality Standard | IPC-A600F/MIL-STD-1050D |
Design file format | Ki-CAD,Pro-E Gerber RS-274X,274D,Eagle and AutoCAD'S DXF,DWG |
Assembly Options | Surface Mount ( SMT ) . Thru-Hole ( THT ) . Box building , COB , Conformal Coating , Potting and Encapsulations , IC Programming & Marking Gringing & Lettering |
Types of Solder | Leaded and Lead-free (RoHS Compliant ) PCB assembly services |
Stencils | Laser cut stainless steel stencils |
Minimum Order | 1 pieces |
Component Size | Passive Component : we can accept components as small as 01005 . 0201 BGA : we have the ability to handle BGA of 0 . 25mm pitch with X-ray testing Fine Pitch Parts : we can assemble 0 . 25mm fine pitch parts . POP ( Package on Package ) . QFP CCGA , CSP etc Max Component Height : 25mm ( SMT ), Top 120mm / Bot 15mm ( Wave-Solder ) |
Component Package | We accept parts in Reels , Cut Tape , Tube &Tray , Loose Parts and Bulk |
Board Dimension | Min Board Size : No Limited Max Board Size : 680x500mm |
Board Shape | We can assemble boards in Rectangular, Circular and any Odd Shapes |
Board Type | Rigid PCB . Flexible PCB,Rigid-flex PCB, Metal PCB |
Repair& Rework | Repair and rework accepted , Our BGA reballing service with which we can safely remove the misplaced BGA , reball it and put it back on the PCB correctly . It is cost-effective |
Testing | ICT . AOI , X-Ray , Function Test ( FCT ) , Aging Test |
OutPut | 12 SMT lines and 5 DIP lines |
Quality Standard | IPC-A-610E , IS0 13485 : 2003 , ISO 16949 : 2011 , ISO 14001 : 2004 |
