Best Selling Product 220V Din Rail Wall Mounted Timers Power Outlet Socket Digital Timer Switch

Best Selling Product 220V Din Rail Wall Mounted Timers Power Outlet Socket Digital Timer Switch

Category: Time Switches >>>
Supplier: Zhejiang,Ninuo,Electical,Co.,Ltd.

Price:$5.10 - $5.60

Price in USD:Details

Quantity:

Product Overview

Description

Mini Digital LCD Power Timer Programmable Time Switch AC 220V / 110V DC 12V 16A Temporizador Din Rail Timer Switch
Mini digital LCD power timer
Programmable time switch AC 220V
Timer switch
THC15A switch AHC
Microcomputer time control switch AHC
Digital modular distribution box installation
Description :
Type: Time switch
Material: Plastic
Power supply: 200-250V AC 50 / 60Hz
Capacity: 30A
Timing range: 1min-168hours
Program: 16 times a day ON/OFF
Power consumption: <5VA
Interruption: 90 days
Average error: <2sec/day
Temperature range: -10 - 50 degrees Celsius
Humidity: <95%
Size: about 9x4x7cm / 3.54x1.57x2.76 inches
Type(optional): TM919A-1 110V, TM919A-2 220V, TM919A-3 24V, TM919A-4 12V, TM919A-5V
Classification (optional): 1-85-265VAC, 2-120VAC, 3-220VAC, 4-24VDC/AC, 5-12VDC/AC, 6-5VDC
Color: White + Blue

Detailed Images

Product Deatils

Adjustable relay display for voltage and current adjustable voltage protector AC breaker

Operation voltage			AC220V(EU/UK),110V(US),DC12V 24V
Frequency			50/60Hz
Model			THC-1516	THC-1520	THC-1530
AC switching capacity	resistive load	16A	20A	30A
		inductive load	8A	10A	15A
Accuracy			±1s/day at 20 ℃
Power Reserve			60 days
Power Consumption			≤7.5VA
Switching Contact			1 Changeover switch
Min Interval time			1 Min
No.of program			17 groups
Installation Type			Din Rail Mounting
Ambient Temperature			-20 ~ +55℃
