Jigs for Car Production Line
US $32750-$34580
Automatic Screw Bolt Feeder Digital Display Crank Long Arm Nut Welder Spot Welding Machine
- Category: Auto Production Line Equipment >>>
- Supplier: Chengdu Xingweihan Welding Equipment Co. Ltd.
Share on (1600475413464):
Product Overview
Description
Product Description
Input Voltage | AC 380V |
Frequency | 50Hz/60Hz |
Rated Power | 45KVA |
Welding Current | 55A-13000A |
Duty Cycle | 15% |
Automatic Working Time | 0-99S |
Operation Way | Electronic timer continuously |
Protection Grade | IP21 |
Air Supply Pressure | 4kg-8kg |
Cable length | 2.2+2m, 3m, 7m |
Dimension | 740x610x1800 mm |
Weight | 168kg |
MAIN FEATURES
1.The microprocessor control system optimizes the welding parameters. Using advanced digital control technology and user friendly design, all you have to do is select the welding current corresponding to the work piece thickness to achieve the best welding results.
2.Various welding procedures are available such as shrinking, washer welding, dent pulling spot welding, flattening, waveform wire
welding, stud welding, OT washer welding, triangle washer welding etc.
3.overweight and overheat protection of welding transformer without any worries for the users.
4.Uniquely designed gun cable support arm allows flexible movement with 360 rotation.
5.Designed for dent pulling of different kinds of car steels such as conventional steel, stainless steel, etc.
6.6 sets data for each welding option, totally 60 sets can be saved.
7.Impulse-type welding ,perfect weld joint ,4T control and relieving the fatigue causing from long-term pressing posture.
8. Countdown is available while welding
2.Various welding procedures are available such as shrinking, washer welding, dent pulling spot welding, flattening, waveform wire
welding, stud welding, OT washer welding, triangle washer welding etc.
3.overweight and overheat protection of welding transformer without any worries for the users.
4.Uniquely designed gun cable support arm allows flexible movement with 360 rotation.
5.Designed for dent pulling of different kinds of car steels such as conventional steel, stainless steel, etc.
6.6 sets data for each welding option, totally 60 sets can be saved.
7.Impulse-type welding ,perfect weld joint ,4T control and relieving the fatigue causing from long-term pressing posture.
8. Countdown is available while welding
Detailed Images
Related Products
Packing&Shipping
Company Profile
Why Choose Us
*Your reply will be replied within 24 hours.
*Fast delivery time and good after service.
*Keep the mass production as the sample in high quality.
*Freight forwarder: faster, safer, and convenient.
*Good factory price.
*Guaranteed for one year.
*Providing overseas services.
Long-term Experience of Welding Machine Manufacturing
*Fast delivery time and good after service.
*Keep the mass production as the sample in high quality.
*Freight forwarder: faster, safer, and convenient.
*Good factory price.
*Guaranteed for one year.
*Providing overseas services.
Long-term Experience of Welding Machine Manufacturing
Customized Designing and Manufacturing
Many customer's trust
FAQ
Q1: What does your factory produce?
A: We produce and export all kinds of welding machine. We can also design and develop the
welding machine according to your requirement.
Q2: What about your standard delivery time?
A: Normally 15 days after receiving the deposit, delivery date will be longer on customized products.
Q3: Can I visit your factory?
A: Of course, we can pick you up in the airport.
Q4: Do you have CE certificate?
A: YES, we have CE, CCC, ISO.
Q5: Where do your factory located?
A: Our factory located in NO.538 Xingfu Road, Xindu, Chengdu, China.
Q6: Will you send engineer to help installing the welding machine?
A: Of course. If you need, we can send our engineer to fly to your factory to help installing the welding machine, train your
workers and make sure the welding machine running well before he leave.
welding machine according to your requirement.
Q2: What about your standard delivery time?
A: Normally 15 days after receiving the deposit, delivery date will be longer on customized products.
Q3: Can I visit your factory?
A: Of course, we can pick you up in the airport.
Q4: Do you have CE certificate?
A: YES, we have CE, CCC, ISO.
Q5: Where do your factory located?
A: Our factory located in NO.538 Xingfu Road, Xindu, Chengdu, China.
Q6: Will you send engineer to help installing the welding machine?
A: Of course. If you need, we can send our engineer to fly to your factory to help installing the welding machine, train your
workers and make sure the welding machine running well before he leave.
