Product Overview
Description
Product Description
| Performance | Engine | Diesel tow tractor | ||||||||
| Model | TD15 | TD20 | TD25 | TD30 | TD35 | TD50 | TD60 | |||
| Max. Drawbar Pull | KN | 15 | 20 | 25 | 30 | 35 | 50 | 60 | ||
| Max.towed weight at dry even concrete surface | With One Trailer | Kg | 15000 | 20000 | 25000 | 30000 | 35000 | 50000 | 60000 | |
| Travel Speed | Forward | km/h | 22 | 25 | 25 | 27 | 26 | 26 | ||
| Backward | km/h | 20 | 22 | 22 | 22 | 21 | 21 | |||
| Max.Gradeability | No Load | % | 38 | 38 | 35 | 35 | 35 | 35 | ||
| Dimension | Overall Length (With Coupler) | mm | 3000 | 3015 | 3015 | 3180 | 4160 | 4160 | ||
| Overall Width | mm | 1440 | 1440 | 1440 | 1440 | 2000 | 2000 | |||
| Overall Height | mm | 1450 | 1450 | 1450 | 1450 | 1450 | 1450 | |||
| Wheel Base | mm | 1600 | 1620 | 1620 | 1605 | 2300 | 2300 | |||
| Front Overhang | mm | 630 | 635 | 635 | 665 | 944 | 944 | |||
| Rear Overhang (With Coupler) | mm | 750 | 760 | 760 | 910 | 900 | 900 | |||
| Front Tread | mm | 1250 | 1250 | 1250 | 1250 | 1590 | 1590 | |||
| Rear Tread | mm | 1200 | 1200 | 1200 | 1160 | 1490 | 1490 | |||
| Min.Turning Radius / Outer | mm | 2980 | 3000 | 3000 | 3000 | 4500 | 4500 | |||
| Floor Height | mm | 425 | 425 | 425 | 425 | 450 | 450 | |||
| Seat Height | mm | 980 | 980 | 980 | 980 | 1020 | 1020 | |||
| Center Height Coupler | mm | 305/405 | ||||||||
| Min.Ground Clearance | mm | 165 | 165 | 165 | 150 | 180 | 180 | |||
| Tire | Tire Size | Front | 6.50-10-10PR | 6.50-10-10PR | 7.50-16-8PR | |||||
| Rear | 7.00-15-12PR | 7.00-15-12PR | 8.25-20-14 | |||||||
| Weight | Truck Weight (No Load) | kg | 3400 | 3450 | 3900 | 4400 | 5100 | 8900 | ||
| Weight Distribution | Front Axle | kg | 1165 | 1160 | 1120 | 1080 | 1350 | 1900 | ||
| Rear Axle | kg | 2235 | 2290 | 2780 | 3320 | 3750 | 7600 | |||
| Engine | Model | MITSUBISHI S4S/China engine | MITSUBISHI S4S | MITSUBISHI S4S-DT | YuChai 6J160-T300/cummins | |||||
| Displacement | cm3 | 3331 | 3331 | 3331 | 3331 | 6.494 | ||||
| Rated Output | KW/RPM | 47/2500 | 47/2500 | 47/2500 | 62/2500 | 118/2200 | ||||
| Rated Torque | N.M/RPM | 200/1600 | 200/1600 | 200/1600 | 265/1800 | 650/1400-1700 | ||||
| Automatic Transmission model | EXEDY KT | ITALY PST2 | ||||||||
| Transmission type | Hydraulic Transmission | |||||||||
| Streering | Integral Power Steering | |||||||||
| Brake | Service Brake | Hydraulic Drum Brake | ||||||||
| Parking Brake | Acting On Driving Wheel Brake | |||||||||
Company Information
Our Services
FAQ:
Any questions, welcome to contact us, we ill be always help you and support you.
1.May I know how soon I can get the machine after I transfer the deposit?
Usually, if the quantity is less than 20 units, we can finish the production in 15-20days. We will try our best to offer the machines to you as soon as possible.
2.How long the product warranty period?
The product warranty period is 18 months or 2000 hours.
3.How long have you engaged in this industry?
We have been engaged in this industry for more than 20years, Our hot products sold at home and abroad by our own foreign trade department and some trading company.
