Product Overview
Description
Marking Area | 75*75mm 110*110mm 150mm*150mm 175mm*175mm 200*200mm 300*300mm |
Marking Depth | ≤1.2mm |
Marking Speed | 10000mm/s |
Minimum Line Width | 0.012mm |
Minimum Character | 0.15mm |
Repeated Precision | ±0.003mm |
Life-span of Fiber Laser Module | 100 000hours |
Beam Quality | M2 <1.5 |
Focus Spot Diameter | <0.01mm |
Output Power of Laser | 10%~100% continuously to be adjusted |
System Operation Environment | Windows XP / W7--32/64bits / W8--32/64bits |
Cooling Mode | Air cooling--Built-in |
Temperature of Operation Environment | 15℃~35℃ |
Power Input | 220V / 50HZ / single phase or 110V / 60HZ / single phase |
Power Requirement | <400W |
Communication Interface | USB |
Machine Dimension/after package | 920*830*1160mm |
Net Weight/gross weight | 120/170kg |
Optional | Rotary Device, Moving Table, other customized Automation |
50W Fiber Laser Marking Machine Equipped JPT Laser Source and Dia.80mm Rotating Head. Laser Power: 50W. Marking Area: 175*175mm
Engraving Depth:≤1mm(0.024in)
Laser Source: JPT LP+ Series; Repetition Rate Frequency: 1-600kHZ; Pulse Duration: 200ns. Control board : BJ JCZ
board(Original).EZCAD2. Compatible with Windows XP/Vista/7/8/10. Stable performance and high reliability.
Applicable material: Fiber laser marking machine can work on all metals such as aluminum,stainless steel, brass, copper etc. and
some of nonmetal such as nylon ,light button, ABS , PVC ,PES etc.
Imported laser scanning system makes the marking speed up to 7m/s; Re-position precision is 0.002mm; High-Rate of
Electrical-Optical Conversion: up to 70%.
Engraving Depth:≤1mm(0.024in)
Laser Source: JPT LP+ Series; Repetition Rate Frequency: 1-600kHZ; Pulse Duration: 200ns. Control board : BJ JCZ
board(Original).EZCAD2. Compatible with Windows XP/Vista/7/8/10. Stable performance and high reliability.
Applicable material: Fiber laser marking machine can work on all metals such as aluminum,stainless steel, brass, copper etc. and
some of nonmetal such as nylon ,light button, ABS , PVC ,PES etc.
Imported laser scanning system makes the marking speed up to 7m/s; Re-position precision is 0.002mm; High-Rate of
Electrical-Optical Conversion: up to 70%.
Product Description
FAQ
Q: Which Port of loading?
A: Mainly ship from Ningbo port / Shanghai Port/Guangzhou Port.
Q: What is your MOQ?
A: All the products can be mixed in one container with low MOQ 30-50pcs.Sample can be accepted.
Q: What is the Lead Time?
A: Normally it needs 7-15 days.
Q: What is the Payment Terms?
A: T/T/ western union/Paypal.
A: Mainly ship from Ningbo port / Shanghai Port/Guangzhou Port.
Q: What is your MOQ?
A: All the products can be mixed in one container with low MOQ 30-50pcs.Sample can be accepted.
Q: What is the Lead Time?
A: Normally it needs 7-15 days.
Q: What is the Payment Terms?
A: T/T/ western union/Paypal.
