YANTRS BHS 4055MGX Waterproof 55KG High Speed RC Digital Steel Oblique Gear Brushless Servo Motor Applied in Airplane Car
- Category: >>>
- Supplier: Huizhou Yanchuang Technology Co. Ltd.
Share on (1600480797628):
Product Overview
Description
Specification
Operation Travel | 60°±1 |
Control System | PWM Control |
Operation Voltage Range | 6V ~8.4V |
Weight | 80G |
Operation Temperature Range | -20C°~ +60C° |
Dimensions | 40*20*40.50mm |
Motor Type | Brushless Motor |
Potentiometer Type | Direct Drive |
Gear Material | Steel Gear |
Case Material | Aluminum Case |
Product Description
Features:
1. All-metal CNC aluminum alloy shell with better heat dissipation
2. Newly upgraded steel helical gear, Operation and torque output will be smoother and smoother
3. High quality double ball bearing
4. Wide voltage range (6V-8.4V)
5. Super long life brushless motor
6. Digitally controlled amplifier
7. IP67 waterproof standard
Product Information：
Model: BHS-4055MGX
Size: 40x20x40.50mm
Weight: 80g(without servo horn)
Gear: Steel
Torque/Speed: 58kg-cm/0.12sec/60°8.4V
49kg-cm/0.14sec/60°7.4V
42kg-cm/0.17sec/60°6V
Motor Type: Brushless Motor
Signal Type: Digital Control
Case Material: CNC 6082 Aluminum Case
Connector Wire Length: 300MM JR Plug
Include:
Servo*1
Accessories package*1
1. All-metal CNC aluminum alloy shell with better heat dissipation
2. Newly upgraded steel helical gear, Operation and torque output will be smoother and smoother
3. High quality double ball bearing
4. Wide voltage range (6V-8.4V)
5. Super long life brushless motor
6. Digitally controlled amplifier
7. IP67 waterproof standard
Product Information：
Model: BHS-4055MGX
Size: 40x20x40.50mm
Weight: 80g(without servo horn)
Gear: Steel
Torque/Speed: 58kg-cm/0.12sec/60°8.4V
49kg-cm/0.14sec/60°7.4V
42kg-cm/0.17sec/60°6V
Motor Type: Brushless Motor
Signal Type: Digital Control
Case Material: CNC 6082 Aluminum Case
Connector Wire Length: 300MM JR Plug
Include:
Servo*1
Accessories package*1
