1 ton 2 ton all electric stacker electric hydraulic lift forklift without front legs stacker

Share on (1600484373388):


Price:$3,200.00 - $3,300.00

Quantity:


Product Overview

Description



Product Description


 Dual-purpose stacker truck with the functions of loading and unloading and short-distance transportation of goods; suitable for loading and unloading of goods in workshops, warehouses, stations, etc.; with the characteristics of stable lifting, labor-saving, flexible rotation and easy operation; it is an ideal tool for reducing labor intensity, improving work efficiency and achieving safe handling






























































































































































































































































































































Main parameters of 1.5T counterweight forward moving forklift

Serial number

projectCompanyRise 1.6mRaise 2 metersRaise 2.5mRaise 3 metersRise 3.5m
1Rated lifting capacitykg15001500150015001500
2lengthForkmm1070*100*401070*100*401070*100*401070*100*401070*100*40
The fork moves forward and the pedal is retractedmm30003000300030003000
  The fork does not move forward, and the pedal is retractedmm24002400240024002400
  Pedal lengthmm400400400400400
3widthWheel widthmm860860860860860
Frame widthmm860860860860860
4heightHeight of non lifting gantrymm20801600185020802350
Maximum lifting height during operationmm16002000250030003500
Maximum height of gantry during operationmm26003000350040004500
5Minimum ground clearancemm100100100100100
6Drive wheel sizemm250*80250*80250*80250*80250*80
7Auxiliary wheel sizemm125*50125*50125*50125*50125*50
8Drive wheel typemmPolyurethanePolyurethanePolyurethanePolyurethanePolyurethane
9electric machineryLifting motorkw2.22.22.22.22.2
Drive motorkw1.21.21.21.21.2
10Rated power of batteryV/Ah24/18024/18024/18024/18024/180
11Override mode HandleHandleHandleHandleHandle
12Speed regulation mode Stepless speed regulationStepless speed regulationStepless speed regulationStepless speed regulationStepless speed regulation
13Reference service timeh6-86-86-86-86-8
14Mass of complete machine under standard no-load statekg16201650168017101750
19Minimum turning radius (pedal down)mm15001500150015001500
20Maximum operating speed without loadkm/h88888
21Maximum operating speed under full loadkm/h55555
22Maximum climbing gradient under full load°3-53-53-53-53-5
23Maximum hook traction under full loadkN15001500150015001500
24Load center distancemm550550550550550
25The lifting height of each tonnage ismm16002000250030003500
26The corresponding height of the gantry ismm20801600185020802350






Packaging & Shipping


 Package for 1.5 ton 2 ton 3 ton forklift machines electric for sale is: packed by pvc film and cartton, loaded on pallet





Our Services




Certitications







Company Information





Taixing Rulift Machinery Co., Ltd was established in 2005 ,a professinal storage equipentt manufacturer, which covering an area of 18000 square meters. we are specialized in various types of Hydraulic manual handing pallet jack and stacker, drum stacker, diversified lift table platform, pallet truck with weighing scale, semi-electric and full electric stacker and pallet truck. the mainly applications of our is for warehousing, port, air port, factory workshop.Our factory owns a completed line of advanced equipment, such as welding robots, hydraulic presses machines and etc. Mean while, we also have professional technical team in designing and producing which can meet different requirements from customers, that's why we can support OEM production line, we offer 24 hours pre-sales and after-sales support, to ensure in-time communication between clients and us. Besides, most of our products are CE certified, all those ensure our qualified product. With the great reputation on quality, we sells to Europe, Southeast Asia and many other countries, and our products are parised by our customers not only at home but also in abroad. Moreover, our company is located in Taixing City, Jiangsu Province, Which is close to Shanghai, at the same time there is a Yangtai Airport near our factory, so, it is very convenience for customers to make a visit, we welcome the customers all over the word.


.jpg





FAQ


 Q1. What is your terms of packing?
A: Generally, we pack our goods in paper package and Iron pallet.
We can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance. Or As negotiated
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 5 to 30 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.
Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q6: How do you make our business long-term and good relationship?
1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from..jpg
