industrial advanced condensing steam turbine
US $1000-$3000
Msw small rice husk waste biomass gasification power plant wood sawdust updraft syngas gasifier stove for power generation
- Category: >>>
- Supplier: Shandong PULITA New Energy Technology Co. Ltd.
Share on (1600486252951):
Product Overview
Description
Msw small rice husk waste biomass gasification power plant wood sawdust updraft syngas gasifier stove for power generation
Products Overviews
Gasification principles of biomass is to convert agriculture / forestry products and wood processing remains (including rick husks, wood powder, branches, offcuts, corn straws, rice straws, wheat straws, cotton straws, fruit shells, coconut shells, palm shells, bagasse, corncobs etc.) into syngas by Biomass Gasifier. Syngas then is used as fuel in thermal and electric power applications.
Product Paramenters
Model | HBF-100 | HBF-200 | HBF-300 | HBF-600 | HBF-900 | HBF-1200 | HBF-1500 | ||||||
Gasifier type | Updraft Fixed-bed Gasifier / Downdraft Fixed-bed Gasifier / Fluidized Bed Gasification System (Alternatively) | ||||||||||||
Rated Gas Production (Nm³/hr) | 100 | 200 | 300 | 600 | 900 | 1200 | 1500 | ||||||
Biomass Gasify Agent | Air/Steam | ||||||||||||
Biomass Moisture Requirement | Fluidized Bed ≤ 15%-20%; Updraft Fixed-bed ≤ 25%-40%; Downdraft Fixed-bed ≤ 20%-25% | ||||||||||||
Raw Material Size Requirement | Fluidized Bed: Granularity ≤ 20mm Fixed-bed: Length ≤ 10mm-80mm, Diameter 20mm-80mm | ||||||||||||
Control System | PLC Integrated Control | ||||||||||||
Heat Value of Gas | ≥ 1100-1500 kcal/Nm³ | ||||||||||||
Gas Purification Method | Physical / Srubber / Electrical Precipitator (Alternatively) | ||||||||||||
Ash Discharge Type | Dry Type / Wet Type (Alternatively) | ||||||||||||
Raw Material
Working Principle
The Advantages of Biomass Gasifier
1) Biomass gasification successfully conquers the disadvantages of biomass, such as low flammability and wide diversity.
2) Biomass gasification system is characteristic of small land requirement and environment friendly.
3) It’s one of the most effective way of biomass utilization.
1) Biomass gasification successfully conquers the disadvantages of biomass, such as low flammability and wide diversity.
2) Biomass gasification system is characteristic of small land requirement and environment friendly.
3) It’s one of the most effective way of biomass utilization.
Gas Composition Data of Several Raw Materials After Gasification ( for Reference only )
Raw Materials | Gas Content | Heat Value (Kcal/Nm³) | ||||||||||
CH4 (%) | CO2 (%) | CO (%) | CnHm (%) | H2 (%) | O2 (%) | |||||||
Rice Husk | 3.16 | 15.32 | 13.69 | 0.11 | 14.55 | 0.91 | 1173 | |||||
Wood Chips | 2.62 | 14.86 | 17.34 | 0.09 | 18.97 | 0.72 | 1365 | |||||
Apricot Shell | 3.13 | 14.74 | 15.23 | 0.14 | 14.54 | 1.01 | 1221 | |||||
Gasification Plant Data of Several Raw Materials
No. | Material Name | Consumption of Raw Materials (kg/kW·H) | Raw Material Gas Production (Nm³/kg) |
1 | Rice Husk | 1.6-1.8 | 1.6-2.2 |
2 | Rice Straw | 1.6-1.7 | 1.6-2.3 |
3 | Sawdust | 1.4-1.5 | 1.9-2.4 |
4 | Woodchips | 1.3-1.5 | 1.9-2.3 |
5 | Coconut Shell | 1.5-1.8 | 1.5-2.0 |
6 | Palm Kernel Shell | 1.5-1.6 | 1.5-2.1 |
