Factory Price Stainless Steel Water Storage Tank Equipment Cosmetics Storage Containers
- Category: Chemical Storage Equipment >>>
- Supplier: ZHEJIANG,LEADTOP,PHARMACEUTICAL,MACHINERY,CO.,LTD
Share on:
Product Overview
Description
Products Description
Usage:
This stainless steel tank is mainly used in medicine, food, chemical industry for storage or transit liquid and gaseous materials.
Structure and types:
Structure and types:
Have two types Vertical and horizontal, end cover can be oval, dish, cone and flat cap etc. depending the storage materials, it can use external insulation layer. According the different installation can be buried type, floor type, or hanging etc.
Features
1. The stainless steel parts contact with material all adopt mirror polished handle, can achieve the CIP and meet the health standards.
2. Tube length of the connector according to 1.5D standard design, the nozzle and tank welds showed arc-like, meet the GMP requirements.
3. Glass tube liquid level meter, easy for observe, easy for measurement of free demolition of the design can be achieved online cleaning.
4. Flange quick open manholes, clean, sanitary, easy to use.
5. Rotary cleaning ball, a thorough cleaning can clean every corner.
Technical Data
Model | ZG500 | ZG1000 | ZG2000 | ZG3000 | ZG6000 | ZG10000 | ZG20000 | ||||||
Volume (L) | 500 | 1000 | 2000 | 3000 | 6000 | 10000 | 20000 | ||||||
Design pressure (Mpa) | Common pressure(Atm) | ||||||||||||
Design tem (℃) | 100 | ||||||||||||
Thickness (mm) | 3.0 | 3.0 | 3.0 | 3.0 | 4.0 | 5.0 | 8.0 | ||||||
Weight (kg) | 165 | 220 | 330 | 410 | 740 | 1190 | 3250 | ||||||
Size (mm) | φ900*1700 | φ1000*2300 | φ1200*2800 | φ1500*3000 | φ1700*4000 | φ1900*4900 | φ2400*5300 | ||||||
Company Profile
Our Company
Zhejiang LeadTop Pharmaceutical Machinery Co.,ltd well known as LTPM China. Since year 1996, we are start manufacturing Oral Solid Dosage Pharmaceutical Machinery includes Mixing Machine, Drying Equipment, granulation line, IBC Bin and Bin Washing Machine. As year passed, LTPM China absorb advanced domestic and abroad technology, we export machinery to more than 30 countries all over the world. LTPM China is considered one of the major Pharmaceutical Machinery Supplier and exporter in China mainland. Professional,Enthusiasm, Service and Team Work has been always our value to create for our Staff and customers. As year 2012 we position our value as “A Pharma Machinery Division, For A Better Life”, creating a Win-Win Platform for our clients and staff for a better life is our vision.
Our Certificates
ISO, CE, SGS, BV Certified Company.
Our Machinery Manufacturing Workshop
Imported CNC Machining Centre makes all parts process accurate. Own R&D team with more than 20 years engineering expereince, can customize the equipment and packaging line to your satisfaction.
Professional Business Team
Warm, professional business team, careful response to your inquiry, timely response rate of more than 93%, higher than the average level of the industry.
Packing & Shipping
All machine delivery with anti rust spray, film wrapping and Sea shipping affordable wooden box.
FAQ
Q: What price terms you offer?
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange everything for you!
Any other doubts about our machine, please feel easy to contact with us.
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange everything for you!
Any other doubts about our machine, please feel easy to contact with us.
