Product Overview
Description
Professional industrial Lathe mathines machinery and tooling machines exporter
Specifications | C6132D | C6136D | C6140D | ||||
capacity | Max.Swing over bed | 320mm | 360mm | 400mm | |||
Max.swing over carriage | 180mm | 200mm | 240mm | ||||
Max.length of workpiece | 750/1000mm | ||||||
Width of bed | 312mm | ||||||
Section of turning tool | 20x20mm | ||||||
Spindle | Spindle speeds | 30-1600r/min(12 steps) | |||||
Spindle hole | Ø52mm | ||||||
Spindle nose | C6 | ||||||
Spindle taper | MT6 | ||||||
Feed | NO. of feed | Longitudinal(0.039-1.05mm),cross(0.019-0.52mm) | |||||
Range of metric threads | 0.5-20mm(25 kinds) | ||||||
Range of inch threads | 80-1.75TPI(35 kinds) | ||||||
Range of module threads | 0.25-10mm | ||||||
Range of diametral threads | 160-3.5DP(30 kinds) | ||||||
Tailstock | Max.tailstock spindle travel | 100mm | |||||
Tailstock spindle diameter | Ø60mm | ||||||
Taper of tailstock | MT4 | ||||||
Main motor | 3/4kw | ||||||
Packing dimensions | Overall dimension for 750mm | 2000x1130x1540 | |||||
Overall dimension for 1000mm | 2250x1130x1540 | ||||||
Weight | Overall dimension for 750mm | 1400kg | 1500kg | 1700kg | |||
Overall dimension for 1000mm | 1500kg | 1600kg | 1800kg | ||||
ABOUT US
ANTS Machine is a leading Chinese industrial lathe machinery andtooling machines supplier, located in the downtown of Shanghai City.Since our company was founded, based on the advantage of BOCHI which is the No.1 Chinese machine tool manufacturer, we continuallyintroduce top Chinese lathe machinery enterprises and their productsto international markets and export them to approximately 30countries and several regions across the globe, such as BOCHI,Shanghai Machine Tool, SPARK etc. Today we stand tallamidst a number of competitors across the world.
