ZONJLI standard truck scale 120 ton 3x18m vehicle weighing weighbridge truck scales
- Category: >>>
- Supplier: Jiangxi Zonjli High-Tech Co. Ltd.
Share on (1600489443979):
Product Overview
Description
Product Overview
Max. Weighing Capacity 120 ton 3x18m weighing platform standard truck scale
It could connect to printer, computer, scoreboard, stabilized voltage supply, power surge protector and other external equipment.
Truck scales are widely used in metallurgy, mining, machinery, chemical, port and all kinds of truck weighing measurement.
FEATURES AT A GLANCE
◆ Material: Q235B, high quality carbon steel
◆ U beam structure, height: 300mm
◆ Automatic co2-protected welding
◆ Conduct shot blasting by horizontal overall shot blasting cleaning machine, to make the adhesion of surface paint is stronger
◆ Through professional software proceeds force analysis of weighing platform, optimization design, to guarantee bearing strength of platform
PRODUCT SPECIFICATIONS
No | Item | Data | ||
1 | Accuracy grade | OIML III | ||
2 | Max.Weighing Capacity | 120 ton | ||
3 | weighing platform size | 3m x 18m | ||
4 | Division value | 20kg | ||
5 | Axle-loading | 45 ton | ||
6 | Thickness of top plate | 8 mm | ||
7 | weighing platform module | 4.5+4.5+4.5+4.5 | ||
8 | load cell qty | 10 |
Successful Project
Project in Australia
Project in Oman
Project in Philippines
