  • 12BB Monolayer Glass 66Cells 36V 645W 650W 655W 660 W665W Standard Solar Panel mono Solar Panel Manufacture
12BB Monolayer Glass 66Cells 36V 645W 650W 655W 660 W665W Standard Solar Panel mono Solar Panel Manufacture
12BB Monolayer Glass 66Cells 36V 645W 650W 655W 660 W665W Standard Solar Panel mono Solar Panel Manufacture
12BB Monolayer Glass 66Cells 36V 645W 650W 655W 660 W665W Standard Solar Panel mono Solar Panel Manufacture
12BB Monolayer Glass 66Cells 36V 645W 650W 655W 660 W665W Standard Solar Panel mono Solar Panel Manufacture
12BB Monolayer Glass 66Cells 36V 645W 650W 655W 660 W665W Standard Solar Panel mono Solar Panel Manufacture
12BB Monolayer Glass 66Cells 36V 645W 650W 655W 660 W665W Standard Solar Panel mono Solar Panel Manufacture
12BB Monolayer Glass 66Cells 36V 645W 650W 655W 660 W665W Standard Solar Panel mono Solar Panel Manufacture

12BB Monolayer Glass 66Cells 36V 645W 650W 655W 660 W665W Standard Solar Panel mono Solar Panel Manufacture

Share on (1600490471972):


Price:$0.15 - $0.25

Quantity:


Product Overview

Description









Electrical Characteristics                 STC （0~+5w）     NOCT
Power Class
JF12M62H-12BB-645
JF12M62H-12BB-650
JF12M62H-12BB-655
JF12M62H-12BB-660
JF12M62H-12BB-665
Test Condition（Pmax/W）
STC   NOCT
STC    NOCT
STC    NOCT
STC    NOCT
STC    NOCT
Maximum Power（Pmax/W）
645    479
650   483
655  486
660     490
665    494
Open Circuit Voltage（Voc/V）
45.00    42.4
45.20    42.60
45.40    42.8
45.6   43
45.8  43.2
Short Circuit Current（Isc/A）
18.22   14.65
18.26  14.68
18.3  14.71
18.34   14.74
18.38  14.78
Voltage At Maximum Power（Vmp/V）
37.60   35.10
37.8   35.3
38    35.5
38.2  35.7
38.4  35.9
Current At Maximum Power （Imp/A）
17.16  13.63
17.2   13.67
17.23  13.7
17.28  13.74
17.32  13.77
Module Efficiency（%）
20.8
20.9
21.1
21.3
21.4


 Operating Parameters
Operational Temperature
‘-40℃~+85℃
Power Output Toleranca
0~+5W
Voe and Isc Tolerance
±3%
Maximum system voltage
DC1000V/1500V
Maximum series fuse rating
25A
Nominal operating cell temperature
45±2℃
Protection class
class II
Protection Ievel of junction box
IP68


Mechanical Loading
Front Side Maximum Static Loading
5400Pa
Rear Side Maximum Static Loading
2400Pa
Hailstone Test
25mm Hailstone at the speed of 23m/s




Solar Cell
>High efficiency PV cell
> Anti-PID
> 100% Full test
Glass
>High light transmission no less than 93%
> Module efficiency is increased 2%
> Service life 25 years
>Anti-reflective glass


Frame
>Frame by Tentop(Black/Silver Optional)
>120N Tensile Strength Frame
> Stress test..
>Anodized aluminium means durable protection
junction box
> Quality diode ensures module running safety
> IP67 or IP68 protection level
> connector：MC4
> Long service life




Anything further question and more solution. Contact us ! 》》》》




We are a high-end manufacturer of solar photovoltaic modules with advanced equipment, technology and quality in the global photovoltaic industry. It distributes photovoltaic panels, solar relative products, solar system solutions and services to a diversified international utility, commercial and residential customer. All products have TUV certification, CQC certification,photovoltaic leader certification, and obtained IS09001 quality system certification, environmental management system certification, and occupational health management system certification.












1. Q: Do you have your own factory?

A: Yes, we have two factories

2. Q: How can I visit your factory?

A: Before you take off from your country, please let us know. We will arrange time to pick you up.

3.Q : When can I get the price?
A : We usually quote within 24 hours after we get your inquiry.

4.Q : Could I have prices of your products?
A : Welcome. Pls feel free to send us an email here. You will get our reply in 24 hours.

5.Q : Can I get a lower price if I order large quantities?
A : Yes, cheaper prices with more bigger quantity orders.
