Dental Operating Microscope Surgical Microscope Dental Endodontic Microscope with Camera Interface
- Category: >>>
- Supplier: Xinhuaguang Medical Technology Group Co. Ltd
Share on (1600492143146):
Product Overview
Description
PRODUCT DESCRIPTION
Dental Operating Microscope Surgical Microscope Dental Endodontic Microscope with Camera Interface | ||||||
Product Name | Dental Operation Equipment | Brand Name | ZHOEK++ | |||
Model Number | DOM-800 | Warranty | 1 year | |||
After-sale Service | Online Technical Support | Illumination | LED | |||
Magnification | 0.4X-2.4X(1:6) | Eyepiece | Wide Field WF12.5X/18B（10 X/18B） | |||
Binocular Tube | 0-200 degree | Usage | Dentist Working Partner | |||
Model Number | DOM800 | |
Application Domain | Dental | |
Electrical data | ||
Power Socket | 220v(+10%/-15%) 50HZ/110V(+10%/-15%) 60HZ | |
Power Consumption | 40VA | |
Safety Class | class I | |
Microscope | ||
Binoculars | 0-200 Binocular Tube | |
Magnification | 0.4X-2.4X(1:6) , total magnification 3.6X-21.6X ( F 250mm) | |
Objectives | F=200mm-450mm | |
Objective Focusing | 250mm | |
Eyepiece | 12.5x/ 18B(10x/18B for optional) | |
Diopter Adjustment | +6D ~ -6D | |
Feild of Veiw | 9.3mm-55.6mm | |
Illumination | ||
Light Source | LED cold light,illumination diameter of light spot Φ50mm with life time >100000 hours, brightness >50000 lux CRI>90 | |
Banlance Arm | 120° Banlance arm | |
Filter | Build-in standard spot, green filter, yellow filter. | |
Power Supply | AC 110V/220V - 220W | |
Stands | ||
Max Extension Range | 1428mm | |
Base | 640mm × 640mm | |
Rotation Angle | 270 degree | |
Movable Floor Stand frame | Including base, column, big cross arm(340mm),small cross arm(650mm) and so on. height:1800mm, The range of up-down≥350mm | |
Brake System | Fine adjustable mechanical brakes for all rotation axes with detachable brake | |
System Weight | 110kg | |
Stand Options | Ceiling mount,Wall mount,Floor stand,Floor plate | |
DETAILED IMAGES
Treatment of dental pulp disease，Periodontal disease， restorative dentistry
ZHOEK++ professional surgery microscope, you see a fashionable, smooth lines, beautiful shape with a sense of modern design of
high-end microscope, and modern consulting room perfect fit. Under the fashionable appearance is full of excellent optical
quality, you have upgraded to a higher level of clinical treatment,bringing you a higher quality, more efficient work experience .
ZHOEK++ operating microscope allows users to easily adjust the focal length without changing the sitting position or opening and
moving the lens. Easier operation to prevent prolonged strain of cervical and lumbar spine.
ZHOEK++ professional surgery microscope, you see a fashionable, smooth lines, beautiful shape with a sense of modern design of
high-end microscope, and modern consulting room perfect fit. Under the fashionable appearance is full of excellent optical
quality, you have upgraded to a higher level of clinical treatment,bringing you a higher quality, more efficient work experience .
ZHOEK++ operating microscope allows users to easily adjust the focal length without changing the sitting position or opening and
moving the lens. Easier operation to prevent prolonged strain of cervical and lumbar spine.
The operating range of the professional-grade operating microscope zoom objective is 200 mm-450 mm, covering almost all the
operating range required for oral treatment.
By adjusting the zoom knob, you can easily tighten the focus anywhere without changing the position of the microscope or your
seat, making your job very easy.
