KCD1 102N on off With LED Light Boat Power 3 pin led rocker Switch 6A 250V 10A 125V customizable
KCD1-102N on off With LED Light Boat Power 3 pin led rocker Switch 6A 250V 10A 125V customizable
KCD1-102N on off With LED Light Boat Power 3 pin led rocker Switch 6A 250V 10A 125V customizable
KCD1-102N on off With LED Light Boat Power 3 pin led rocker Switch 6A 250V 10A 125V customizable
KCD1-102N on off With LED Light Boat Power 3 pin led rocker Switch 6A 250V 10A 125V customizable
KCD1-102N on off With LED Light Boat Power 3 pin led rocker Switch 6A 250V 10A 125V customizable
KCD1-102N on off With LED Light Boat Power 3 pin led rocker Switch 6A 250V 10A 125V customizable

KCD1 102N on off With LED Light Boat Power 3 pin led rocker Switch 6A 250V 10A 125V customizable

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description









Item name
Rocker Switch
Model Number
KCD1-102N
Rated current/voltage
6A 250V 10A 125V
Insulation resistance
≥100M Ω
Contact resistance
≤50MΩ
Dielectric Strength (Interpole)
≥1500VAC/5S
Electrical life
≥10000 times
Use temperature range
T 85
Contacts
3 pin
