VDI TOOL HOLDER B TYPE
Type B1/B3/B5/B7 VDI Tool Holders Static (DIN69880) Turret Face Mounting, Radial tool holder, inverted, right-hand
We have the most complete range of tool holders as BT, DIN69871, CAT, HSK, etc. VDI Tool Holders are with DIN 69880 standard,common types are Form B1, B2, B3, B4, B5, B6, B7, B8, C1, C2, C3, C4, D1, D2, E1, E2, E3, E4 and Form F.
We have the most complete range of tool holders as BT, DIN69871, CAT, HSK, etc. VDI Tool Holders are with DIN 69880 standard,common types are Form B1, B2, B3, B4, B5, B6, B7, B8, C1, C2, C3, C4, D1, D2, E1, E2, E3, E4 and Form F.
Our Radial VDI Tool Holders Static B1/B3/B5/B7 Types are cut from solid pretreated material. They are hardened up to HRC-55~60,and then precisely ground to the highest accuracy standards.
Size | d1 | b1 | b2 | b3 | h1 | h5 | h6 | l1 | l2 |
B1-16x12x24 | 16 | 42 | 23 | 5 | 12 | 20 | 22 | 13 | 24 |
B1-16x12x34 | 16 | 42 | 23 | 5 | 12 | 20 | 22 | 23 | 34 |
B1-20x16x30 | 20 | 55 | 30 | 7 | 12/16 | 25 | 30 | 16 | 30 |
B1-20x16x40 | 20 | 55 | 30 | 7 | 12/16 | 25 | 30 | 26 | 40 |
B1-25x16x30 | 25 | 55 | 30 | 7 | 12/16 | 25 | 30 | 16 | 30 |
B1-25x16x40 | 25 | 55 | 30 | 7 | 12/16 | 25 | 30 | 26 | 40 |
B1-30x20x40 | 30 | 70 | 35 | 10 | 20/16 | 28 | 38 | 22 | 40 |
B1-30x20x60 | 30 | 70 | 35 | 10 | 20/16 | 28 | 38 | 42 | 60 |
B1-40x25x44 | 40 | 85 | 42.5 | 12.5 | 25/20 | 32.5 | 48 | 22 | 44 |
B1-50x32x55 | 50 | 100 | 50 | 16 | 32/25 | 35 | 60 | 30 | 55 |
B1-60x32x60 | 60 | 125 | 62.5 | 16 | 32/25 | 42.5 | 62.5 | 30 | 60 |
B1-80x40x75 | 80 | 160 | 80 | 20 | 40/32 | 55 | 80 | 40 | 75 |
PRODUCT DETAILS
VDI TOOL HOLDER B TYPE
Taper shank standard: DIN 69880
Suitable taper shank: VDI
Outlet water: conventional outlet water
Outlet way
Internal water + outlet water
Hilt hardness: HRC 50-55
Taper shank size: VDI16/20/25/32/40/50/60/80
Applicable machine: turning milling compound machine; Turning center, etc
Outlet way
Internal water + outlet water
Hilt hardness: HRC 50-55
Taper shank size: VDI16/20/25/32/40/50/60/80
Applicable machine: turning milling compound machine; Turning center, etc
High locking strength
Adjustable, extra cooling tube can be added.
High hardness and wear resistance
Shim can be ordered separately, used for small size tool holder.
PROBE HOLDER USAGE
*VDI Provides a fast and accurate way of affixing tools to the Turret;
*Metric Available Upon Request.
*Tool Changes are performed in seconds. Toolholders can be Preset. By Cam Operated Clamping System.
*Metric Available Upon Request.
*Tool Changes are performed in seconds. Toolholders can be Preset. By Cam Operated Clamping System.
*Used for Mazak, Emco-Maier, Hitachi, Seiki, Okuma, Hass, Daewoo Hardinge.
*Toolholders are precision ground, and Hardened.
*Black-oxide finish for long lasting protection.
*Black-oxide finish for long lasting protection.
