MYXL green house uv plastic polycarbonate sheet panel greenhouse structure
- Category: >>>
- Supplier: Myxl Greenhouse Tech And Dev Co. Ltd.
Share on (1600495706514):
Product Overview
Description
Products Description
Advantage of Polycarbonate Greenhouse
* Stable structure, beautiful form, smooth version, remarkable thermal insulation performance.
* Moderate light transmission rate, many rain grooves, large span, drainage volume, strong wind resistance ability, suitable for area of big wind and rainfall.
* PC greenhouse has good light transmittance, low heat conduction coefficient. Polycarbonate sheet has light weight, long service life, tensible strength.
Feature of Polycarbonate Greenhouse
1.Light weight
2.Excellent impact resistance
3.Good light transmission
4.Good weather resistant and UV protection
5.Sound and heat insulation
6.Simple process and installation
7.Excellent fire resistance
Tape | Polycarbonate Greenhouses |
Width | 6m-12m,,customized |
Height | 3m-7m,,customized |
Length | 20m-100m,customized |
Frame | Hot-dip galvanized skeleton |
Cover | PC Sheet |
Material thickness | 4mm,6mm,8mm,10mm |
Color | Clear,white,black,yellow,red,green,orange,etc. |
Warranty | 10-20 years |
Details Images
Cover Material-Pc sheet
Energy saving and environmental protection, hollow structure, light weight, reducing the support force of the frame, a variety of colors are available.
Frame Material
Hot-dip galvanized steel,The greenhouse frame is made of hot-dip galvanized steel pipe, no welding points, not easy tom rust, extend service life.Excellent hot-dip galvanized steel structure and accessories, anti-corrosion
Hot-dip galvanized steel,The greenhouse frame is made of hot-dip galvanized steel pipe, no welding points, not easy tom rust, extend service life.Excellent hot-dip galvanized steel structure and accessories, anti-corrosion
Complentary System
Completed environment-controlled greenhouse is available based on the different regions and its climates, which includes shading,natural ventilation, cooling or heating, fertigation, Irrigation, cultivation, hydroponic and auto-control systems etc.
Shading system
shade net/shading net/sunshade net
color:black,white,green
1. Using high-density HDPE raw materials, anti-ultraviolet, anti-radiation, shading rate up to 95%.
2. The mesh surface is flat, no broken wires, no voids, and encrypted edges.
3. Sunshade and sun protection, wind and wind resistance, heat preservation and moisturizing.
3. Sunshade and sun protection, wind and wind resistance, heat preservation and moisturizing.
Bench and Grow Lights
1.Bench/Seedbed:fixed bench,rotary bench and ebb&flow bench system.High space effiency,convenient for planting and high productive for crops.
2.LED Grow lights:Full-spectrum light output.DLC/ ETL Listed.High efficiency (2.7umol s -1 per watt).High output for high intensity.Ambient temperatures from 0°C（32°F) to 35°C (95°F)
Cooling system
cooling pad and cooling fan
When cooling pad and fan are used simultaneously,fan discharge the heat air which have smell, dust and dirty air to the outside, Fresh cold air through the cooling pad into the greenhouse and replace the hot air, achieve the purpose of the ventilation, cooling, humidification, romove dust, get rid of the stink, and adding lots of oxygen content.
Irrigation System
Sprinkler Irrigation Systems and Drip Irrigation Pipes/Drip Tapes
1.Drip,impulse sprinkler, micro sprinkler and fog spray irrigation system.
2.Water saving and smart.
2.Water saving and smart.
Heating system:
1.Coal-fired heating system, fuel oil heating system, gas heating system, electrical heating system, hot water
heating and etc.2.Energy saving.
1.Coal-fired heating system, fuel oil heating system, gas heating system, electrical heating system, hot water
heating and etc.2.Energy saving.
Packaging & Delivery
Step 1: Design greenhouse drawings and plans
Step 2: Pack the greenhouse covering materials in woven bags
Step 3: Provide an introduction to the greenhouse in English
Step 4: Check the waterproof index for suitable and practical packaging
Step 5: Communicate with logistics to check appropriate details
Step 6: Control the delivery of each line.
According to customer requirements.
Company Profile
Certifications
FAQ
1.The land area is large. Should we use single-span or multi-span?
It is related to the plants and project budget. The multi-span shed is more expensive and saves space, while the single span one is simpler to install and more economical.
2.How to determine the size of the greenhouse?
2.How to determine the size of the greenhouse?
If there is fan and water pad the cooling system, it is better not to exceed 60 m.
If there are shading and blackout systems, should pay attention to the reasonable allocation of bays.
As for the span width, generally 6 m to 12 m. It is highly necessary to consider the climatic conditions and the growth requirements of the plants.
3.Should you choose a round arch or a pointed roof?
The round arch one is better against wind. The spire one is better against snow. And the round arch is cheaper;
4.How to install the greenhouse?
We can send engineers to site for building large scale greenhouse project. As for single greenhouse, it is recommended to install according to our installation guidance, and we can make detailed instructions for our customers;
5.How many 300-square-meter greenhouses can be installed in a cabinet?
It depends on the steel frame sizes. Generally, one 20' container can fit in 10-15 sets of single span greenhouse. And 40' can fit in about 20-24 sets of that;
6.Thickness of zinc layer of hot-dip galvanizing/thickness of zinc layer of galvanized zinc
220-275g, 20μ/150g, 15 -18μ;
7.How do we guarantee quality?
First we always uses high quality raw material. Second, we always make a pre-production sample before mass production to ensure that the finished products meet the needs of customers all the time; Third, there is always a final inspection before shipment;
8. What can you buy from us?
Various types of greenhouses, such as glass greenhouse, polycarbonate greenhouse, and film greenhouse. Meanwhile, there is also hydroponic greenhouse, garden greenhouse, commercial greenhouse.
9.Why choose us?
We are greenhouse manufacturer, ex-factory price, good quality with moderate price. Overall solution for greenhouse engineering. With rich experience, professional design, good after-sales service, installation supervision.
If there are shading and blackout systems, should pay attention to the reasonable allocation of bays.
As for the span width, generally 6 m to 12 m. It is highly necessary to consider the climatic conditions and the growth requirements of the plants.
3.Should you choose a round arch or a pointed roof?
The round arch one is better against wind. The spire one is better against snow. And the round arch is cheaper;
4.How to install the greenhouse?
We can send engineers to site for building large scale greenhouse project. As for single greenhouse, it is recommended to install according to our installation guidance, and we can make detailed instructions for our customers;
5.How many 300-square-meter greenhouses can be installed in a cabinet?
It depends on the steel frame sizes. Generally, one 20' container can fit in 10-15 sets of single span greenhouse. And 40' can fit in about 20-24 sets of that;
6.Thickness of zinc layer of hot-dip galvanizing/thickness of zinc layer of galvanized zinc
220-275g, 20μ/150g, 15 -18μ;
7.How do we guarantee quality?
First we always uses high quality raw material. Second, we always make a pre-production sample before mass production to ensure that the finished products meet the needs of customers all the time; Third, there is always a final inspection before shipment;
8. What can you buy from us?
Various types of greenhouses, such as glass greenhouse, polycarbonate greenhouse, and film greenhouse. Meanwhile, there is also hydroponic greenhouse, garden greenhouse, commercial greenhouse.
9.Why choose us?
We are greenhouse manufacturer, ex-factory price, good quality with moderate price. Overall solution for greenhouse engineering. With rich experience, professional design, good after-sales service, installation supervision.
