uv ctp cron ctcp fiber array,cron ctp optic

Model

U832

U848

U864

Exposing Method

External Drum

Imaging System

32 channel

48 channel

64 channel

Discrete 400~410nm laser

Output Speed

16 plates/hour

22 plates/hour

28 plates/hour

1030×800mm, 2400dpi

Plate Size

Max.1130×920mm, Min. 400×300mm

Exposing Size

Max.1130×906mm

Plate Type

UV plate, High-sensitive PS plate

Plate Thickness

0.15mm~0.3mm

Resolutions

2400dpi

Repeatability

±5μm(Continuous exposure over four times on the same plate with a temperature of 23℃ and 60% RH )

Interface

USB2.0 / USB3.0 (Recommended option is USB2.0)

Plate Loading

Alternative autoloader system

Net Weight

1200KG

Device Size

2127×1405×1058mm(W×D×H)

Power

Single phase:200V~240V; Max power(Peak value):4KW

Environment

Recommended temperature: 21~25℃ Allowed temperature: 15~30℃ Humidity: <70%
