diodo laser ctp cron

Model

U

Exposing Method

External Drum

Imaging System

32 channel

Discrete 400-410nm laser

Output Speed

16 plates/hour

1030×800mm, 2400dpi

Plate Size

Max.1130×920mm,  Min.400×300mm

Exposing Size

Max.1130×906mm

Plate Type

UV plate, High-sensitive PS plate

Plate Thickness

0.15mm-0.3mm

Resolutions

2400dpi

Repeatability

±5μm(Continuous exposure over four times on the same plate with a temperature of 23℃ and 60% RH )

Interface

USB2.0 / USB3.0 (Recommended option is USB2.0)

Plate Loading

Manual place plate, then autoload

Net Weight

900KG

Device Size

2320×1080×960mm(W×D×H)

Power

Single phase:200V-240V; Max power(Peak value):4KW

Environment

Recommended temperature: 21-25℃ Allowed temperature: 15-30℃ Humidity: <70%
