8 pin usb round cable connector XHB Connector for Favorable price KLDZ
- Category: >>>
- Supplier: Zhejiang Kuaili Electronic Co. Ltd.
Share on (1600499083468):
Product Overview
Description
| Rated current | Content |
| Series | XHB Series Pressure welding Bar Connector(2.5mm) |
| PLACE OF ORIGIN | ZHEJIANG,CHINA(MAINLAND) |
| PRODUCT NAME | XHB 2.5mm pitch 3 pin 8 pin female 4 pin 14 pin male electronic wire Connector |
| ROW | Single row |
| POLES | 2-16P |
| PITCH | 2.5mm |
| MATERIAL | PA66 & Brass Tin |
| COLOR | White |
| FEATURES | Fire-proof, Flame retardancy |
| RATED VOLTAGE | 250V AC,DC |
| RATED CURRENT | 3A |
| CONTACT RESISTANCE | 20mΩ MAX |
| INSULATION RESISTANCE | 1000MΩ MIN |
| WITHSTAND VOLTAGE | 1000V AC/min |
| WORKING TEMPERATURE | -25℃~85℃ |
| APPLICABLE WIRES | AWG#28~#22 |
WAFER
Part No.:XHB-NA, XHB-NAW, XHB-NAWD
Housing: PA66 UL94V-0(2)
Contact: Brass,Tin plated
Solder lug: Phos. Bronze, Tin plated.
HOUSING
Part No.:XHB-NY
Material: PA66 UL94V-0(2)
TERMINAL
Part No.: XHB-TE
Material: Phos. Bronze,Tin Plated
