China factory Frequency Inverter Medium Voltage Variable Frequency Drive Mini Vfd 0.4kw 5.5kw Oil Pump Drive Frequency Changer
- Category: >>>
- Supplier: Shenzhen Robotsy Mechanical Electrical Equipment Co. Ltd.
Share on (1600499137873):
Product Overview
Description
Product Descriptions
VT200 Series Mini Type AC Drive are developed for general applications of small power and OEM market.It applies SVC andV/F control technology,marking the functions of PID,multiple-speed step,DC braking(optional),Modbuss communication,as well as less installation space.VT200 Series AC drive is for small automation equinment of economical type,especially suitable for electroni equipment,for packaging wood,glass and other small power transmission.
Main features:
1.Output frequency:0-3200Hz.
Main features:
1.Output frequency:0-3200Hz.
2.Fire mode.
3.Remote control operation keypad,convenient for remote control.
4. Sensorless Vector Control 180% torque at 0.5Hz.
5. Overload:150% for 1 minute and 180% for 10 seconds.
6. Build-in simple PLC function,textile swing frequency function,fix length control Module.
7. Auto current limiting and voltage limiting and under-voltage restrain.
3.Remote control operation keypad,convenient for remote control.
4. Sensorless Vector Control 180% torque at 0.5Hz.
5. Overload:150% for 1 minute and 180% for 10 seconds.
6. Build-in simple PLC function,textile swing frequency function,fix length control Module.
7. Auto current limiting and voltage limiting and under-voltage restrain.
8.Output automatic voltage regulation function(ACR).
9. Built-in PID regulation function to facilitate the realization of closed loop control of the temperature,pressure and flow.and reduce the cost of the control system.
10. MODBUS communication protocol.
9. Built-in PID regulation function to facilitate the realization of closed loop control of the temperature,pressure and flow.and reduce the cost of the control system.
10. MODBUS communication protocol.
Product Description
Specification
item | value |
Place of Origin | China |
Guangdong | |
Brand Name | Advinver |
Model Number | VT200-4T-0.75G |
Warranty | 24 MONTHS |
Type | Frequency Inverter |
Certification | ce |
Customized | Yes |
Control Mode | Feedback vector control |
Rated Power | 0.75kw |
Nominal Voltage | 380v |
power phase number | 3 |
Outstanding Feature | High start torque/non-stop at momentary power failure/Fire mode |
Input voltage | 380V 3 Phase |
Output Frequency | 0-3200Hz |
output current | 2.1A |
output power | 0.75KW |
Communication | Modbus485 CANOpen Profibus-DP CANlink |
Protection | Overload Overcurrent Overvoltage |
Protection Class | IP 20 |
Delivery time | 7 Working Days |
Customized support | OEM/ODM/Distribution |
Packing & Delivery
FAQ
Q 1: How to choose suitable VFD for my machine?
A: Please send us your motor information, power and input Voltage, load/Machine after motor also if can. we will provide you most suitable model type.
Q 2: What's the payment term?
A: We accept T/T, L/C, D/A, D/P, WESTERN UNION, PAYPAL, CASH, etc.
Q 3: What's the delivery time?
A: For 1000pcs inverter, it usually takes one week to finish.
Q 4: What's the standard of package?
A: Below 75kW, it's carton package; 75kW and above, it's wooden package.
Q 5: How you control quality?
A: 100% full-load burn-in tested before shipping for fast commissioning and start-up
Our inverters strictly follow ISO9001 quality control system. After four times quality inspect and high temperature testing we will print "QA" pass.
Q 6: What's your production capacity?
A: We can finish 10000pcs inverter per month. Also we can receive rush order, more details please contact us.
Q 7: Which market do you already sell?
A: We already ship to Europe, Middle East, South America, Asia, Africa, etc.
Q 8: What kind of certificate you have?
A: We have ISO, CE, CB, TUV, etc.
Q 9: Do you accept OEM business?
A: Yes, we accept OEM and ODM with your authorization. For some items we have MOQ. For more questions, feel free to send us inquiry.
A: Please send us your motor information, power and input Voltage, load/Machine after motor also if can. we will provide you most suitable model type.
Q 2: What's the payment term?
A: We accept T/T, L/C, D/A, D/P, WESTERN UNION, PAYPAL, CASH, etc.
Q 3: What's the delivery time?
A: For 1000pcs inverter, it usually takes one week to finish.
Q 4: What's the standard of package?
A: Below 75kW, it's carton package; 75kW and above, it's wooden package.
Q 5: How you control quality?
A: 100% full-load burn-in tested before shipping for fast commissioning and start-up
Our inverters strictly follow ISO9001 quality control system. After four times quality inspect and high temperature testing we will print "QA" pass.
Q 6: What's your production capacity?
A: We can finish 10000pcs inverter per month. Also we can receive rush order, more details please contact us.
Q 7: Which market do you already sell?
A: We already ship to Europe, Middle East, South America, Asia, Africa, etc.
Q 8: What kind of certificate you have?
A: We have ISO, CE, CB, TUV, etc.
Q 9: Do you accept OEM business?
A: Yes, we accept OEM and ODM with your authorization. For some items we have MOQ. For more questions, feel free to send us inquiry.
