High Strength Safety Carbon Fiber Core Steel Core Galvanized Ss Non Rotating Oil Metal Universal Wire Rope
- Category: >>>
- Supplier: Shanghai Shineworld Group Co. Ltd.
Share on (1600499174201):
Product Overview
Description
Product Introduction
1.Application:
Galvanized steel wire adopts hot galvanizing vertical process, with uniform thickness, smooth surface and strong corrosion resistance. It is widely used for ACSR, power cables and overhead cables.
2. Specification
| Nom. Dia.(mm) | Tolerance(mm) | Tensile strength (N/mm²) | Zinc coating (g/m²) |
| 1.6 | ±0.03 | 1450 | 195 |
| 2.0 | ±0.04 | 1450 | 215 |
| 2.5 | ±0.05 | 1410 | 245 |
| 3.0 | ±0.05 | 1410 | 255 |
| 3.5 | ±0.06 | 1380 | 265 |
Note: Normative references BS-EN-10244. BS EN 10257 and BS 5467 can also be satisfied.
3.Product Properties:
| ² Fast Delivery | ² High Carbon Steel |
 | |
| ² Strong hardness | ² Strong Corrosion Resistance |
 | |
| Wire Diameter(mm) | Coil φ Inner Dia (mm) | Coil φ Outer Dia (mm) | Coil Height Aprx. (kg) | Coil Weight Aprx. (kg) |
| 0.90 1.25 1.60 | 350±30 | 650±30 | 600±100 | 350±100 |
| 0.90 1.25 1.60 | 500±50 | 700±50 | 600±100 | 500±100 |
| 2.0 2.5 3.15 | 500±50 | 900±50 | 850±100 | 850±150 |
| 2.5 3.15 | 600±50 | 1000±50 | 1000±50 | 1350±150 |
4.Packing & Delivery
