Product Overview
Description
Product Introduction
Rechargeable module design allows series and parallel removable 48volt 50Ah lithium battery for home energy storage
The Home Energy Storage System (Split Type) provides the energy storage for PV users and backup power support for the important electrical equipment. The battery system can store excessive power generated by PV system at daytime, and can utilize the stored energy (if necessary) to supply power for electrical equipment at night, thus improving the utilization efficiency of photovoltaic power generation, shaving peaks and filling valleys, providing backup power for emergency and important electrical equipment to avoid data and financial loss caused by sudden power outage.
NO. | Name | Function |
1 | Positive electrode | connect the positive electrode of external device |
2 | Negative electrode | connect the negative electrode of external device |
3 | Capacity indicator, alarm indicator | Indicate working status, battery capacity |
4 | Address DIP switch | Change product code when multiple units are connected in parallel |
5 | CAN interface | Connect external device |
6 | RS485 interface | Connect external device |
7 | Power switch | Power switch |
8 | Ground point | Avoid accidental leakage of electricity |
9 | Support rack | Fix product on the support |
Product Features:
1. Battery has passed test and verification of capacity and cycle life.
2. Lifespan is 2-3 times longer than lead-acid battery.
2. Lifespan is 2-3 times longer than lead-acid battery.
3. Spraying process is adopted on the surface of sheet metal parts, and coating can be maintained for more than 5 years without falling off and rusting.
4. The volume is 2/3 of lead-acid battery and weight is its 1/3, which is more portable.
5. Our battery meets IP54 requirement. The shell is dust-proof and waterproof, and socket can be sprayed with water.
4. The volume is 2/3 of lead-acid battery and weight is its 1/3, which is more portable.
5. Our battery meets IP54 requirement. The shell is dust-proof and waterproof, and socket can be sprayed with water.
Details Images
Items | Technical Data |
Product Code | HY006 |
Battery Type | Lithium iron phosphate battery |
Nominal Voltage(V) | 51.2V |
Rated Capacity(Ah) | 85Ah |
Rated Energy(Wh) | 4352wh |
Output Voltage Range (V) | 44.8V＜U＜58.4V |
Output Power (W) | ＜5000W |
Working Temperature℃ | Charge(0 ℃- 55℃) Discharge(-10℃ - 55℃) |
Dimension(L*W*H) (MM) | (500mm×446mm×312mm)±2mm（Not include bulge part） |
Weight(KG) | ≤77±2Kg（Subject to real battery） |
Application
Home energy storage system is widely used in many scenarios such as emergency power supplies, communication power supplies, and home energy storage. It provides power support for the important electrical equipment such as LED light, Fan, mobile phone, TV, laptop, digital camera, drone, and kitchen appliances, etc.
Certifications
Company Profile
Product packaging
FAQ
Q1.Are you a factory or trading company?
A: We are a professional manufacturer specialized in new energy enterprise integrating R&D, production, sales and technical services of battery system. Our battery products mainly involves household ESS, Portable power station, battery in RV, UPS, and many other fields.
Q2.How could I know if this product is suitable for me?
Q2.How could I know if this product is suitable for me?
A: Before ordering, we will provide every details of the product for your reference, or you could tell us your detailed requirements, our technician will recommend the most suitable product for you.
Q3.Is it possible to provide after-sales service?
Q3.Is it possible to provide after-sales service?
A: We have a team of professional after-sales engineers, can provide full after-sales service online or on-site.
Q4.Can I visit your factory?
A: Welcome to visit our factory. We build business relationship with many well-known factory. We can visit the cooperative factories if you need, and you could know more thing about Saichuan technology according that.
Q5.I haven't done business with you guys before,how can i trust your company?
A: We would trade on Alibaba online to make sure your money is safely; we has rich experience of battery storage solutions. Saichuan had established business relationship with so many famous brands, Quality is reliable.
Q6.What's the shipment terms and delivery time of your company?
A: It depends on the quantity of your order. Meanwhile,our board attach importance to foreign orders ,thus the orders aboard will have priority over it at home.
