Product Overview

Description

LPG Model Centrifugal Atomizer, whey Spray Dryer, whey spray drying equipment

1, Rotary atomizer spray dryer / Rotary atomizer spray dryer price / Rotary atomizer type spray dryer

2, Low energy consumption and large handling capacity

3, Easy operation and control



Rotary Atomizer Spray Dryer Description

LPG Rotary atomizer spray dryer is a wide applied process in liquid process shaping and drying industry. Particularly it is suitable for producing powder, granule or block solid product from solution, emulsion, suspending liquid and pumped paste liquid. Therefore when the distribution of granule size, final moisture, bulk density, granule shape of finished product must be conformed to accuracy standard, the spray drying is an ideal process.



Rotary Atomizer Spray Dryer Price Application

LPG rotary atomizer spray dryer price is widely used in foodstuff, pharmaceutical and chemical industry, such as egg powder, amino acid product, protein, blood, food flavor, food ingredients, pectin, carrageenan, spirulina, herbal extraction, pigment, cocoa, mushroom, PAC, malt dextrin, collagen, juice, yeast, Coffee, Creamer, coconut, milk, gelatin, gum and acacia etc.



Rotary Atomizer Type Spray Dryer Working Principle

After filtering and heating, the hot fresh air enter into the air distributor at the top of drying chamber, distributed in spiral way uniformly from up to down. At the same time, the feeding liquid is pumped to the top atomizer, then be sprayed to extremely fine mist liquid drop. Through the short time of direct contact with hot air, the moisture evaporated at once, the solid remains to be powder. The dry powder will be discharged continuously from the bottom of drying tower and cyclone collector, the exhaust air will be discharged after cleaning.



Parameters of Rotary Atomizer Type Spray Dryer Price

No.	Item	Model	Qty	Material	Notes
Feeding system
1	peristaltic pump	BT-100	1set	Sanitary	0.3Kw
2	Feeding pipe		1set	SUS304
Circulation system
1	Suction blower	9-19	1set	SUS304	0.75KW
2	Air valve		1set	SUS304
3	Hot air pipe		1set	SUS304
4	Air out pipe		1set	SUS304
5	Pipe fittings		1set	SUS304
Air system
1	Air filter		1set	SUS304	Initial and middle
2	Air heater	12Kw	1set	SUS304
3	Pipe fitting		1set	SUS304
4	Hot air pipe		1set	SUS304	Insulation
Main machine
1	Drying chamber	D1000H2200	1set	SUS304
2	Air distributor		1set	SUS304
3	Air cover		1set	SUS304
4	Atomizer	LPG5/Dia 50mm	1set	SUS304	Air driven
5	Light	100W	1set
6	Manhole		1set	SUS304
7	Insulation			Glass fiber
8	Hammer	SK40	2sets	Aluminum
Powder collection system
1	Cyclone	XF170	1set	SUS304
2	Discharge valve		1set	SUS304
3	Product jar		1set	SUS304
4	Air pipe	Quick opening	1set	SUS304
Control system
1	Control box		1set	SUS304
2	PLC	SIEMENS	1set
3	Touch screen	SIEMENS	1set
4	Contactor	SIEMENS	1set
