C41 400kg Pneumatic Forging press Hammer blacksmith power forging hammer for sale
- Category: >>>
- Supplier: Tengzhou Datong Machine Tool Co. Ltd.
Share on (1600499944760):
Product Overview
Description
DTMC
Product Description
Introduction of 400 kg (880 lbs) blacksmith forge free power hammer
Blacksmith forge free power hammer from 150kg to 2000kg are widely used in the industrial open die forging. can do drawing-out, upsetting, punching, chiseling, forging welding, bending and twisting etc forging process. It is also used for forging in bolster dies.
Features:
1. Unlike steam hammers or air hammers fed from a supplementary compressor, the Pneumatic forging hammer with its self-contained cylinder,require no ancillary power raising plant.
2. The Pneumatic forging hammer is equipped with a self-priming lubricating oil pump, during operating, it can realize the automatic lubrication.
3. Easy to operate, by manipulating the hand lever or foot-pedal, all operating functions—idle run, top setting, pressing down, single blow, light or full series blow can be obtained as desired.
Blacksmith forge free power hammer from 150kg to 2000kg are widely used in the industrial open die forging. can do drawing-out, upsetting, punching, chiseling, forging welding, bending and twisting etc forging process. It is also used for forging in bolster dies.
Hammers are self-contained pneumatic power hammers. The design is based on the time proved designs of the old European pneumatic hammers many which are still in use today. With a self-contained power hammer, you require no external air supply or high-pressure
hoses.
You can forge heavy stock and immediately switch to thin light stock with no adjustments. With a self-contained hammer, you have
tremendous forging power (a combination of ram weight, downward air force, and velocity) plus precise control.
The Anyang hammers are engineered to run for decades in harsh factory environments. The frames are cast iron, like the old Nazel, Buche, and Massey hammers. Cast iron is more expensive to manufacture compared to fabricated hammers but they are heavier, do not
flex over time.
The internal parts are forged steel and precision machined. There are no internal rubber air hoses to deteriorate over time. The drive belts are external to the machine for easy adjustment and away from harmful oil.
The crankshaft has large tapered roller bearings set in a case filled with grease. This design provides for decades of trouble-free forging.
hoses.
You can forge heavy stock and immediately switch to thin light stock with no adjustments. With a self-contained hammer, you have
tremendous forging power (a combination of ram weight, downward air force, and velocity) plus precise control.
The Anyang hammers are engineered to run for decades in harsh factory environments. The frames are cast iron, like the old Nazel, Buche, and Massey hammers. Cast iron is more expensive to manufacture compared to fabricated hammers but they are heavier, do not
flex over time.
The internal parts are forged steel and precision machined. There are no internal rubber air hoses to deteriorate over time. The drive belts are external to the machine for easy adjustment and away from harmful oil.
The crankshaft has large tapered roller bearings set in a case filled with grease. This design provides for decades of trouble-free forging.
Features:
1. Unlike steam hammers or air hammers fed from a supplementary compressor, the Pneumatic forging hammer with its self-contained cylinder,require no ancillary power raising plant.
2. The Pneumatic forging hammer is equipped with a self-priming lubricating oil pump, during operating, it can realize the automatic lubrication.
3. Easy to operate, by manipulating the hand lever or foot-pedal, all operating functions—idle run, top setting, pressing down, single blow, light or full series blow can be obtained as desired.
Specification
Rated weight of the tup(kg) | 400 | ||||
Minimum blow energy(kj) | 9.5 | ||||
Number of blows per minute(min-1) | 120 | ||||
Height of working area (mm) | 530 | ||||
Distance between tup centre axis and frame front(mm) | 520 | ||||
Maximum round steel can be forged(Diameter)(mm) | 240 | ||||
Maximum square steel can be forged(mm) | 220 x 220 | ||||
Motor | Type | Y200L-4-B3 | |||
Rate power(kw) | 30 | ||||
Weight of the hammer (kg) | Hammer | 8000 | |||
Anvil block | 4800 | ||||
Outside size(mm) | 2785x1400x2884 | ||||
