Large current 250V 5A 10A 16A H21 Metal Case Automatic Bimetal Thermostat Switch For Transformer
Large current 250V 5A 10A 16A H21 Metal Case Automatic Bimetal Thermostat Switch For Transformer
Large current 250V 5A 10A 16A H21 Metal Case Automatic Bimetal Thermostat Switch For Transformer
Large current 250V 5A 10A 16A H21 Metal Case Automatic Bimetal Thermostat Switch For Transformer
Large current 250V 5A 10A 16A H21 Metal Case Automatic Bimetal Thermostat Switch For Transformer

Large current 250V 5A 10A 16A H21 Metal Case Automatic Bimetal Thermostat Switch For Transformer

Share on (1600501398784):


Price:$0.15 - $0.20

Quantity:


Product Overview

Description



Products Description


Electrical Rating
DC-12V max 12A; DC-24V max 10A; AC-125V max 8A; AC-250V max 16A
Open temperature
(30~150)±5°C; 5°C a step
Reset temperature
2/3 of the action temperature with tolerance of ±15°C. Reset temperature can also be provided according to customers' requirement.
Life times
10000 times
Size
L20mm W8mm H4mm for 250V 16A
L18.5mm W7.5mm H3.8mm for 250V 10A
Lead wire
#20 red 3135,or #18 3135 end half tripping, length is 70mm, or according to customer’s require
Contact Closure resistance
≤50mΩ
Insulation resistance
≥100mΩ
Used for
H20 thermal protector is applicable to chargeable battery, ballast, massager, micro motor, transformer, electric tools, heat
electric appliance and instrument etc.
Certificate approved
UL CQC TUV KC ROHS
