Model | WSM-160 | TIG200P | |
Rated input power | 1-Phase 220V,50/60Hz | ||
Rated input capacity (kVA) | 5 | 7 | |
Rated input current (A) | 24 | 31 | |
Rated output current (A) | 10-160 | 10*200 | |
Rated output voltage (V) | 10.4-16.4 | 10.4-18 | |
Open circuit voltage (V) | 68 | 73 | |
Rated duty cycle (%) Room temperature 40℃ | 35 | ||
Peak current adjusting range (A) | 10-160 | 10-200 | |
Base value current adjusting range (A) | 10-160 | 10-200 | |
Impulse frequency (Hz) | 0.5-200 | ||
Pulse duty ration (%) | 0.1-0.9 | ||
Lag time (S) | 1-10 | ||
Power factor | 0.83 | ||
Efficiency (%) | 80 | ||
Dimension (L*W*H) (mm) | 380*185*335 | 450*200*385 | |
Weight (Kg) | 11.4 | 14 |
