Price:$25.00 - $35.00

Quantity:


Product Overview

Description





Fast and Stable Thin Mini Barcode Scan Engine Embedded 2D 1D Barcode Scanner Module USB barcode scan engine barcode scanner module usb embedded 2d barcode scanner module


Product Description


Optical System
640 pixels(H)x 480 pixels(V)
Illumination Element
Aiming: 617nm LED; Illumination 3200K White LED
Depth of Field
 40 mm - 280 mm @UPCA -13 mil 100 %,PCS 90%
Scan Angle
38° (H) x 25° (V)
Min. Bar Width
 0.1mm(4mil)@Code 39, PCS=90%
Scan Mode
Trigger mode, Auto-sensing, Continuous scan, Pulse mode
Print Contrast
> 30%(UPC/EAN 100% , PCS 90%)
System Interface
TTL232 (12pin), USB 1.1 (HID Keyboard、Virtual COM Port)
Dimensions
28.2mm x 20.5mm x 11.8mm
Weight
About 5g
Input Voltage
DC 3.3V±5%
Operating Current
 130 mA ±5%（Typical）, 300 mA ±5%（Max.）
EMC
CE EN55022 B, FCC Part 15 Class B, VCCI, BSMI
Operating Temperature
-20℃~50℃



Decoding Capability
           (1D  2D)
UPC/EAN/JAN,UPC-A & UPC-E,EAN-8 & EAN-13, JAN-8 &JAN-13, ISBN/ISSN, Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN128,Code 93,Interleaved 2 of 5 (ITF),Addendum 2 of 5, IATA Code,MSI/Plessy, China Postal Code,Code 32 (Italian Pharmacode),RSS14,RSS Limited, RSS Expanded PDF417 Micro

PDF417 Data Matrix QR Code Micro QR Code Aztec Code Maxi Code

Reads barcode reliably of cell phone screens
Humidity
5%~95% (non-condensing)
Light Level
0~100,000Lux（fluorescence ）
Storage Temperature
-40℃~+70℃




Mini Best Price Wholesale Stable RFID Embedded 1D/2D UPC Scan Module QR Code Reader Module qr code reader module embedded 1d/2d upc scan module rfid scanner module
