Intel Core i5 12400F Used Processor 6 Cores up to 4.4 GHz 65W DDR4 Memory CPU Support Socket FCLGA1700 Motherboard Z590 Z690

Product Overview

Description



New Intel Core i5 12400F Processor 6 Cores up to 4.4 GHz 65W DDR4 Memory CPU Support Socket FCLGA1200 Motherboard Z590 Z690

The Intel Core i5-12400F is a desktop processor with 6 cores, launched in January 2022. It is part of the Core i5 lineup, using the Alder Lake-S architecture with Socket 1700. Thanks to Intel Hyper-Threading the core-count is effectively doubled, to 12 threads. Core i5-12400F has 18MB of L3 cache and operates at 2.5 GHz by default, but can boost up to 4.4 GHz, depending on the workload. Intel is making the Core i5-12400F on a 10 nm production node, the transistor count is unknown. The multiplier is locked on Core i5-12400F, which limits its overclocking potential.
With a TDP of 65 W, the Core i5-12400F consumes typical power levels for a modern PC. Intel's processor supports DDR4 and DDR5 memory with adual-channel interface. For communication with other components in the computer, Core i5-12400F uses a PCI-Express Gen 5 connection. This processor does not have integrated graphics, you will need a separate graphics card.
Hardware virtualization is available on the Core i5-12400F, which greatly improves virtual machine performance. Additionally, IOMMU virtualization (PCI passthrough) is supported, so that guest virtual machines may directly use host hardware. Programs using Advanced Vector Extensions (AVX) can run on this processor, boosting performance for calculation-heavy applications. Besides AVX, Intel is including the newer AVX2 standard, too, but not AVX-512.



Intel® Core™ i5-12400F Processor (18M Cache- up to 4.40 GHz)
Essentials
Product Collection	12th Generation Intel® Core™ i5 Processors
Code Name	Products formerly Alder Lake
Vertical Segment	Desktop
Processor Number	i5-12400F
Status	Launched
Launch Date	Q1'22
Lithography	Intel 7
Use Conditions	PC/Client/Tablet
CPU Specifications
Total Cores	6
# of Performance-cores	6
# of Efficient-cores	0
Total Threads	12
Max Turbo Frequency	4.40 GHz
Performance-core Max Turbo Frequency	4.40 GHz
Performance-core Base Frequency	2.50 GHz
Cache	18 MB Intel® Smart Cache
Total L2 Cache	7.5 MB
Processor Base Power	65 W
Maximum Turbo Power	117 W
Supplemental Information
Embedded Options Available	No
Datasheet	View now
Memory Specifications
Max Memory Size (dependent on memory type)	128 GB
Memory Types	Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels	2
Max Memory Bandwidth	76.8 GB/s
Expansion Options
Direct Media Interface (DMI) Revision	4
Max # of DMI Lanes	8
Scalability	1S Only
PCI Express Revision	5.0 and 4.0
PCI Express Configurations	Up to 1x16+4 |  2x8+4
Max # of PCI Express Lanes	20
Package Specifications
Sockets Supported	FCLGA1700
Max CPU Configuration	1
Thermal Solution Specification	PCG 2020C
TJUNCTION	100°C
Package Size	45.0 mm x 37.5 mm
Advanced Technologies
Intel® Gaussian & Neural Accelerator	3
Intel® Thread Director	No
Intel® Deep Learning Boost (Intel® DL Boost)	Yes
Intel® Optane™ Memory Supported	Yes
Intel® Speed Shift Technology	Yes
Intel® Turbo Boost Max Technology 3.0	No
Intel® Turbo Boost Technology	2
Intel® Hyper-Threading Technology	Yes
Intel® 64	Yes
Instruction Set	64-bit
Instruction Set Extensions	Intel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2
Idle States	Yes
Enhanced Intel SpeedStep® Technology	Yes
Thermal Monitoring Technologies	Yes
Intel® Volume Management Device (VMD)	Yes
Security & Reliability
Intel® Standard Manageability (ISM)	Yes
Intel® AES New Instructions	Yes
Secure Key	Yes
Intel® OS Guard	Yes
Execute Disable Bit	Yes
Intel® Boot Guard	Yes
Mode-based Execute Control (MBEC)	Yes
Intel® Control-Flow Enforcement Technology	Yes
Intel® Virtualization Technology (VT-x)	Yes
Intel® Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® VT-x with Extended Page Tables (EPT)	Yes
