Meanwell XLG 150 L AB 150W 120 ~214V Input IP67 Waterproof Dimmable LED Driver Input 110V High Voltage Transformer Electric

Wide input range 100~305V AC( Class I)

Full power output at 70~100% Constant power mode operation

Metal case with IP67, suitable for outdoor application

Surge protection with 6KV/4KV (10KV/6KV optional)

3 in 1 dimming function (Dim to off and Isolation design)

India (EESL) version with Input Over Voltage Protection can survive input voltage stress of 440Vac for 48 hours

Protection functions: OVP/SCP/OCP/OTP

Life time >50,000 hrs. and 5 years warranty

Applications

Skyscraper lighting

Street lighting

Floodlight Lighting

Stage lighting

Fishing lighting

Horticulture lighting

Bay lighting

DMX power supply

Type HL for use in class I, Division 2

XLG-150 series is a 150W LED AC/DC driver featuring the constant power mode.XLG-150 operates from 100~305VAC and offers models with different rated current ranging between 700mA and 12500mA. Thanks to the high efficiency up to 93%, with the fanless design, the entire series is able to operate for -40℃~+90℃ case temperature under free air convection. The design of metal housing and IP67 ingress protection level allows this series to fit both indoor and outdoor applications. Moreover the innovative environment-adaptive capability allows this series to reliably light on the LEDs for all kinds of application environments in almost any spots that may install LED luminaires in the world. XLG-150 series comply with the latest version of IEC61347/GB7000.1-2015 and UL8750 international safety regulations. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the safety of both user and luminaire system during installation.

1.Q:Can I have a sample order firstly ? what's your MOQ limit?
A: Yes, sample order is acceptable. And we do not have MOQ limi.

2.Q:What's about the lead time and shippment?
A: For common type like APV LPV HLG ELG LRS DR MDR series, we have enough stock. Sample Order can be delivered within 2 days, Bulk Order can be delivered within 2~7 days after payment, not common type need 10~35 days after payment, for detail lead time, please contact our sales.
For shipping, we often use DHL, FedEx, UPS, and TNT. And they take 3-5 days to arrive. For bulk order, we recommend to send goods by Air or by Sea to save your transportation cost.

3.Q:How does your factory do regarding quality control?
A: Quality is priority.We always attach great importance to quality controlling for to the very end.Our factory has gained UL,ENEC,PSE,CCC,CB,CE,ErP,SAA etc authentication.

1. What we sell is 100% Genuine Mean Well Power Supply.

2. We are distributors and manufacturers in China.

3.Alibaba assessed over 10 years Gold Supplier and 20 years of industry experience.
4.Inspected by the inspection Institution of Bureau Veritas Certification.
5.Price is negotiable if you have large quantity demand
6.100% QC inspection Before Shipping.
7.Best Quality & Best Service with Competitive price.
8.Shipping will be the most economical for you and freight cost is informed in advance for your consideration.decision for the shipping terms will be made according to your requirements.
