Product Overview
Description
Product Overview
General Description of Bucket Chain Gold Dredger
The machinery has great ability to adapt to different environments. It is an ideal machinery to dredge sand and gravels for its simple structure and convenience to maintain, especially for the site which is filled with rock and hard soil. And it can also be used in other aspects like salt pond dredging, hard bank exploiting, channel cleaning. The machinery is the non-replaceable choice for sand and rock supplier all over the world for its advantage like reliable function, long working life and lower investment( no need the excavator), good working capacity(500-3000 cubic meters/day).
Features of Gold Bucket Chain Dredger from HIKOS
1) The gold bucket chain dredger are designed according to clients specific mining conditions and requirements.
2) Dredging depth could be min 5 meters and max 30 meters.
3) Processing capacity could be 50tph-400tph.
4) The chain bucket system digs the materials from river/sea bottom, convey it up and feed into the trommel.
5) Double sieve trommel screen with NSK bearings and high pressure water spray pipes on both sides for washing, screening and separating.
6) Double gold recovery systems to ensure highest recovery rate of gold (up to 98%).
7) Water supplying systems with multiple sets of big power submersible slurry pumps, hoses, valves, etc.
8) Powering system with Cummins diesel generator with all batteries, cables and wires.
9) Gold refinery plant to make final product of gold bars.
10) Easy for installation, operation and maintaining.
11) One-Step gold mining solutions from A to Z.
2) Dredging depth could be min 5 meters and max 30 meters.
3) Processing capacity could be 50tph-400tph.
4) The chain bucket system digs the materials from river/sea bottom, convey it up and feed into the trommel.
5) Double sieve trommel screen with NSK bearings and high pressure water spray pipes on both sides for washing, screening and separating.
6) Double gold recovery systems to ensure highest recovery rate of gold (up to 98%).
7) Water supplying systems with multiple sets of big power submersible slurry pumps, hoses, valves, etc.
8) Powering system with Cummins diesel generator with all batteries, cables and wires.
9) Gold refinery plant to make final product of gold bars.
10) Easy for installation, operation and maintaining.
11) One-Step gold mining solutions from A to Z.
The main equipment of the ship from head to stern in turn is:
- - Underwater wheel system
- - Forward hoist
- - Bridge gantry frame
- - Bridge
- - Bridge winch
- - Main frame and chain bucket wheel
- - Gravel screening device
- - Gravity separation equipment
- - Tail transport equipment
- - Forward hoist
- - Bridge gantry frame
- - Bridge
- - Bridge winch
- - Main frame and chain bucket wheel
- - Gravel screening device
- - Gravity separation equipment
- - Tail transport equipment
PRODUCT SPECIFICATIONS
bucket chain gold dredger main parameter | ||||||||||||
Model | Working capacity | Dredging depth | Pontoon length | Total Power | Bucket number | Chain number | ||||||
HIKOS-BCD80 | 80m3/h | 7m | 16m | 60KW | 54pcs | 112pcs | ||||||
HIKOS-BCD120 | 120m3/h | 15m | 28m | 120KW | 70pcs | 140pcs | ||||||
HIKOS-BCD140 | 140m3/h | 15m | 28m | 120KW | 70pcs | 140pcs | ||||||
HIKOS-BCD200 | 200m3/h | 15m | 28m | 160KW | 62pcs | 124pcs | ||||||
HIKOS-BCD300 | 300m3/h | 15m | 28m | 200KW | 62pcs | 124pcs | ||||||
Details Images
1.Chain bucket system
Name: chain and bucket system
Chain material: forged high-manganese steel
Bucket material: High-Manganese steel with forged lips, anti-tearing
Bucket size: depending on the dredger processing capacity
Function: to dig the materials from pond/river/sea bottom
Name: chain and bucket system
Chain material: forged high-manganese steel
Bucket material: High-Manganese steel with forged lips, anti-tearing
Bucket size: depending on the dredger processing capacity
Function: to dig the materials from pond/river/sea bottom
2.Screening System
Name: Gold Trommel Screen
Size (mm): φ1500*3500 or according to processing capacity
Remark: 2 layer trommel screen
Function: for washing, screening and separating the minerals
Water spray pipes: on both sides of the trommel
Mesh size: `12mm and 6mm or according to clients requirement
Name: Gold Trommel Screen
Size (mm): φ1500*3500 or according to processing capacity
Remark: 2 layer trommel screen
Function: for washing, screening and separating the minerals
Water spray pipes: on both sides of the trommel
Mesh size: `12mm and 6mm or according to clients requirement
3.Powering system
Name: Diesel GeneratorPower: 100Kw-350Kw
Brand: Cummins, Weichai, or as required
Function: supplying power to all the systems
4.Control system
Name: Control desk
Type: buttons type
Control person: 1 person
Function: to control all the equipment in the dredger
Name: Control desk
Type: buttons type
Control person: 1 person
Function: to control all the equipment in the dredger
5.Coarse Gold Recovery System
Name: Vibrating Sluice + sluice box
Vibrating sluice type: Hydraulic type
Size: 1m*6m
Sluice box carpet: Mitsubishi brand, imported from Japan
Function: for coarse gold recovery
Recovery rate: 99%
Name: Vibrating Sluice + sluice box
Vibrating sluice type: Hydraulic type
Size: 1m*6m
Sluice box carpet: Mitsubishi brand, imported from Japan
Function: for coarse gold recovery
Recovery rate: 99%
6.Fine Size Gold Recovery System
Name: Knelson type centrifugal concentrator
Processing capacity: 15tph-60tph dry solids
Quantity: 2-4 pcs
Remark: Fully continuous type
Function: for fine size dust gold recovery (-6mm)
Recovery Rate: 99%
Name: Knelson type centrifugal concentrator
Processing capacity: 15tph-60tph dry solids
Quantity: 2-4 pcs
Remark: Fully continuous type
Function: for fine size dust gold recovery (-6mm)
Recovery Rate: 99%
Title goes here.
7.Mercury Amalgamator
Type: V-shaped
Working mode: amlagamator + distiller retort
Function: With the help of Mercury, to extract all the gold out from the concentrates that recovered by the sluice and concentators
Recovery rate: 100%
Type: V-shaped
Working mode: amlagamator + distiller retort
Function: With the help of Mercury, to extract all the gold out from the concentrates that recovered by the sluice and concentators
Recovery rate: 100%
8.Gold Smelting Furnace
Capacity: 10-15kg per batchMoulds: 100g; 200g; 500g; 1000g
Function: to smelting the gold sand and make into final product of gold bars
Bucket Chain Gold Dredger Workshop
Application Project
Dredging machine bucket chain gold dredger in Mongolia for dredging project
Dredging equipment chain bucket gold dredger i in
Kazakhstan for dredging project
Kazakhstan for dredging project
Dredging machine bucket chain gold dredger in Ghana for dredging project
Package and Delivery
Dredging machine bucket chain gold dredger in South Africa for dredging project
By container or in bulk
The bucket chain gold dredger can be shipped in containers or transported by bulk carriers, and each component can be strengthened and fixed, and protect the dredger from damage.
HIKOS Global After-Sales Service
Spare parts:
*Support spare parts are in stock.
*We provide a convenient way for you to order parts. You can simply select the parts you need according to your specs and have them delivered directly to your site.
*Free spare part in the first year and later cost price and services.
*Support spare parts are in stock.
*We provide a convenient way for you to order parts. You can simply select the parts you need according to your specs and have them delivered directly to your site.
*Free spare part in the first year and later cost price and services.
Installation and commissioning:
*After delivery we send two experienced engineers who will be to guide installing and train local workers. 24/7 technical support standby.
*We have offices and agents in some countries and are ready to provide you with solutions.
*After delivery we send two experienced engineers who will be to guide installing and train local workers. 24/7 technical support standby.
*We have offices and agents in some countries and are ready to provide you with solutions.
Maintenance and Support:
*12 months manufacturing warranty on all new installed component parts.
*12 months warranty on engine.
*12 months warranty on hull and all fabricated parts.
*In the event that our customers dredging experience unskilled or mechanical failure or they just need to shoot a minor problem, our engineers are available at customer's services, there are always engineers for installation and training if customers needs. Before dredger ex-factory, it will be tested at our launching site for performance and safety like in the work place.
*12 months manufacturing warranty on all new installed component parts.
*12 months warranty on engine.
*12 months warranty on hull and all fabricated parts.
*In the event that our customers dredging experience unskilled or mechanical failure or they just need to shoot a minor problem, our engineers are available at customer's services, there are always engineers for installation and training if customers needs. Before dredger ex-factory, it will be tested at our launching site for performance and safety like in the work place.
Certificate
Our company has been through ISO 9001 Quality System Certification of CCS. The design, construction, quality inspection is according to the standards and regulations of CCS.
Free Training:
*Our Services offer training and expertise that can help you make sure all of you personnel are operating as safely as possible.
*We will help you teach people at every level of your operation how to operate safely and how to communicate clearly, effectively and openly about any potential safety concerns.
*As technology continues to enhance our world, we are constantly developing and refining advanced technologies. These products, along with the extensive training curriculum offered, provide everything you need to maximize the performance of your equipment, reduce costly downtime, increase your return on investment, improve safety in your workplace, enhance operator performance, and
much more.
*Our Services offer training and expertise that can help you make sure all of you personnel are operating as safely as possible.
*We will help you teach people at every level of your operation how to operate safely and how to communicate clearly, effectively and openly about any potential safety concerns.
*As technology continues to enhance our world, we are constantly developing and refining advanced technologies. These products, along with the extensive training curriculum offered, provide everything you need to maximize the performance of your equipment, reduce costly downtime, increase your return on investment, improve safety in your workplace, enhance operator performance, and
much more.
And we have obtained 26 types of Certificate of Utility Model Patent and 23 types of Certificate of Design Patent.
Company Introduction
Hikos Company Introduction
Weifang Hikos Shipyards Co., Ltd. has passed 30 years development, have own four subsidiaries. Company covers an area of 1500 acres, with more than 500 employees，annual turnover of 230 million RMB. The products are of a great variety including 500-20000m³/h large scale dredging and sand mining equipments, Iron & Gold mining machinery, sand transport ship, water weed collecting ship, multifunctional service boat, tug boat, dredger accessories, HDPE pipe, floater, rubber hose and so on. All the products are with different size for customers’ choices. We can also design and produce special types of machinery according to customers’ requirement. Widely used in sand-excavating, river dredging, desilting, reclamation for channels and land, port construction etc.
Our company has been through ISO 9001 Quality System Certification. The design, construction, quality inspection is according with the standards and regulations of CCS.
Company has Research and Development Center, Quality Department and After-sales Department. Products are exported to more than 50 countries all over the world.
Our company has been through ISO 9001 Quality System Certification. The design, construction, quality inspection is according with the standards and regulations of CCS.
Company has Research and Development Center, Quality Department and After-sales Department. Products are exported to more than 50 countries all over the world.
Why Choose Us
Our advantage:
1. Has 30 years of development
2. Can be designed and customized
3. All products have been through ISO 9001 Quality System Certification of CCS
4. Professional R&D department, quality control department and service department
5. All products test before delivery
6. Engineers are suitable for oversea after-sales service
7. Products have simple structure, easy to install, operate and maintain
8. Short delivery time
9. Exported to 50 countries, and over 300 projects worldwide
2. Can be designed and customized
3. All products have been through ISO 9001 Quality System Certification of CCS
4. Professional R&D department, quality control department and service department
5. All products test before delivery
6. Engineers are suitable for oversea after-sales service
7. Products have simple structure, easy to install, operate and maintain
8. Short delivery time
9. Exported to 50 countries, and over 300 projects worldwide
Customer visiting and signing contract
Signing Contract with Customers
