| Model | WDF8015 | Size | 80x80x15mm |
| Frame | Thermal Plastic,UL 94V-0 | Impeller | Thermal Plastic,UL 94V-0 |
| Bearing Type | Sleeve/Ball | Lead Wire | UL Type |
| Motor | Copper Motor | Insulation | Above 10M Between Lead wire and Frame DC500V |
| Weight | 56g | Rated Voltage | 12v |
| Application | 3D printers,Stage lighting,VR equipment,Intelligent Manicure machine, Projector,High-speed camera,Head mounted display,Automotive industry, Cabinet industry, Power industry,UAV application, Electric forklift,LED lighting industry, Hand held air detector,Charging machine,Nebulizer.Electromagnetic oven,Humidifier,Smart toilet,Intelligent household lampblack machine,Air purifier,Car GPS,Car LED lamp,Aromatherapy machine.CPU cooler,Case. | ||

| Listed Model | Bearing System | Rated Voltage | Operation Voltage | Rated Current | Rated Power | Speed | Air Flow | Static Pressure | Noise Level | Available Features(Optional) | Weight | |||
| VDC | VDC | AMP | W | RPM | CFM | mmH2O | dBA | FG | RD | Thermal Control | PWM | G | ||
| WDF8015HS | Sleeve | 12 | 5.0~14.0 | 0.17 | 2.04 | 3,000 | 30.16 | 2.38 | 34.6 | * | * | * | * | 56 |
| WDF8015MS | 5.0~14.0 | 0.10 | 1.20 | 2,500 | 24.89 | 1.69 | 29.8 | * | * | * | * | |||
| WDF8015LS | 5.0~14.0 | 0.08 | 0.96 | 2,000 | 18.99 | 1.03 | 24.2 | * | * | * | * | |||
| WDF8015HB | Ball | 5.0~14.0 | 0.17 | 2.04 | 3,000 | 30.16 | 2.38 | 34.6 | * | * | * | * | ||
| WDF8015MB | 5.0~14.0 | 0.10 | 1.20 | 2,500 | 24.89 | 1.69 | 29.8 | * | * | * | * | |||
| WDF8015LB | 5.0~14.0 | 0.08 | 0.96 | 2,000 | 18.99 | 1.03 | 24.2 | * | * | * | * | |||
| WDF8015HS | Sleeve | 24 | 12.0~26.0 | 0.10 | 2.40 | 3,000 | 30.16 | 2.38 | 34.6 | * | * | * | * | |
| WDF8015MS | 12.0~26.0 | 0.08 | 1.92 | 2,500 | 24.89 | 1.69 | 29.8 | * | * | * | * | |||
| WDF8015LS | 12.0~26.0 | 0.07 | 1.68 | 2,000 | 18.99 | 1.03 | 24.2 | * | * | * | * | |||
| WDF8015HB | Ball | 12.0~26.0 | 0.10 | 2.40 | 3,000 | 30.16 | 2.38 | 34.6 | * | * | * | * | ||
| WDF8015MB | 12.0~26.0 | 0.08 | 1.92 | 2,500 | 24.89 | 1.69 | 29.8 | * | * | * | * | |||
| WDF8015LB | 12.0~26.0 | 0.07 | 1.68 | 2,000 | 18.99 | 1.03 | 24.2 | * | * | * | * | |||








| Q:Are you a factory or trading company? |
| A:We are a factory. |
| Q:What is the products of our factory ? |
| A: The products are Dc cooling fans , Ac cooling fans, Blower cooling fans, Cpu cooling fan, VGA cooling fan.Our fans from 20mm-220mm . We can also do cooling fans as customers' requirement. |
| Q: Do you provide samples ? is it free or extra ? |
| A: Yes, we could offer the sample for free charge but do not pay the cost of freight. |
| Q: What is your terms of payment ? |
| A: It needs to be decided on the basis of the situation. |
| Q: How long is your delivery time? |
| A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. |
| Other Dimension | |||||
| 20*20*6mm | 20*20*10mm | 25*25*7mm | 25*25*10mm | 35*35*10mm | 40*40*10mm |
| 40*40*10mm | 40*40*20mm | 40*40*28mm | 50*50*10mm | 50*50*15mm | 60*60*15mm |
| 60*60*20mm | 60*60*25mm | 70*70*25mm | 80*80*10mm | 80*80*15mm | 80*80*25mm |
| 90*90*25mm | 92*92*38mm | 120*120*25mm | 120*120*38mm | 135*135*38mm | 140*140*25mm |
| 140*140*38mm | 150*150*50mm | 172*150*38mm | 170*152*51.5mm | 180*180*60mm | 200*200*60mm |
| 220*220*60mm | 225*255*80mm | 280*280*80mm | |||
