Product Overview

Description

Outdoor Ip Sip Wifi Box Touch Panel Hotel Video Door Phone For Villa And Apartment 720p Doorbell

Outdoor Ip Sip Wifi Box Touch Panel Hotel Video Door Phone For Villa And Apartment 720p Doorbell

•


  DIY SIP Broadcast, Intercom, Paging




  Q518 is a SIP video intercom & Paging device for industry application.




  The media stream transmission adopts standard IP/RTP/RTSP protocol. It inherits the advantages of the stability and the sound quality of VoIP Phone. It is perfectly compatible with all the current SIP IPPBX /IMS platforms, such as Asterisk, Broadsoft, 3CX, Elastix, etc.




  It has various functions and interfaces, Such as Intercom, broadcast, video , security, recording, to adapt different application environment, you can very easy to DIY your video intercom & paging equipment. Q518 is the best choice for everyone.




  Highlight Features




  > Easy DIY your Intercom, Broadcast, Paging




  > Small and exquisite, can be embedded in the internal installation




  > Emergency call button interface, active call




  > Interact with IPC camera, you can make a video phone call




  > NVR video recording, standard RJ45 interface




  > Recording output, 3.5mm standard audio interface




  > 10W-30W adaptive output power




  > System online management and upgrade











Datasheet & Specifications:



Intercom	Physical Specifications
· Two SIP lines, supporting SIP 2.0	· 2 RJ45 interface:
(RFC3261) and related RFC	Yellow: WAN port 10 / 100M adaptive, support POE
· Supports two lines RTSP	PoE: 802.3af (Class 3: 6.49 ~ 12.95W)
· Voice broadcast IP address	Black: LAN port (Only connected to the original camera)
· Button or remote volume adjustment	Cable: Super five lines or better
· Switch signal input and output	· 1 blue indicator (SIP status and network status)
· Talkback recording output	· 2 volume plus or minus key
· Handsfree talking	· 1 restore factory settings key
· Default auto answer	· 1 recording output interface: 3.5mm standard
· Dynamic multicast function	audio interface 15 Ohm impedance
· Supports DC or POE power supply	· 1 ground screw
· Support for Function key interface	· 1 way passive speaker interface: Output power:
· Support monophonic active speakers	4Ω, POE / 10W, 12V / 10W,18V / 20W, 24V / 30W;
· Network time synchronization	related to supply voltage.
· Action URL / Active URI remote control	Wire diameter: 18 AWG or larger diameter
	Interface:Pluggable terminal block
Audio	· 1 headset speaker:
· Narrowband speech coding: G.711a / u,	Output: 32 Ohm 1.2V interface:Pluggable terminal block
G.723.1, G.726-32K, G.729AB	· 1 DSS key interface (4 lines): Indicator: Output 5.0V 5mA
· Broadband speech coding: G.722	Sensitivity: -38dB, Impedance 2.2K Ohm bias voltage 2.2V
· Half Duplex Echo Cancellation (AEC)	· 1 short circuit input and output interface (built-in relay):
· DTMF: In-band, out-of-band DTMF(RFC2833)	Relay: MAX DC30V / 1A, AC125V / 0.5A,
	Interface:pluggable terminal block
Networking/ Protocols	· 2 parallel power input interface:
· Supports PoE (802.3af)	12V-24V / 2A DC 1 road for the 5.5mm DC power seat
· Primary and secondary DNS servers supported	1 road way 2Pin pluggable terminal block
· Support VLAN	· Standby power consumption: DC12V 1.32W / POE 1.78W
· Supports SNTP client	· Housing material: aluminum alloy shell
· Support VPN L2TP / PPTP / IPSec	· Installation: Indoor installation
· Supports SRTP	· Operating temperature: -30 ~ 70 ℃
· Support for HTTP / HTTPS web pages	· Storage temperature: -40 ~ 70 ℃
· Support Qos: 802.1p / q, DSCP	· Relative humidity: 10% - 95%
· Support MD5 authentication	· Equipment size: 113x83x28mm
· Supports Web Filter	· Packing size: 138x108x77mm
· DHCP / static / PPPoE	· Equipment weight: 250g
· STUN
