The global sell good quality customized coating fused silica optical glass double concave spherical lens

Product Overview

Description

The global sell good quality customized coating fused silica optical glass double concave spherical lens

Product name	Spherical lens,optical lenses
Material	K9, BK7, ZK2,ZK3,ZK6, CDGM, Corning Fused Silica,  JGS1,JGS2, Corning 7980,Schott, Ohara
Shape	plano convex lens,plano concave lens,double convex lens,double concave lens,meniscus lenses
Focal length	±5mm~1000mm±2%
Size	6mm-300mm
Thickness tolerance	±0.2mm
Surface quality	10/5~80/50
Beveling	<0.2*4.5°
Surface accuracy	λ/10~λ/2





Principle:

The top of the object is also used as two straight lines: one is parallel to the main optical axis and is deflected into a divergent light after passing through the biconcave lens, returning this refracted light to the main focus in the opposite direction; the other passes through the optical center point of the lens, these two lines The straight lines intersect at one point, this is the image of the object.



Application:

The main applications of biconcave lenses: optical imaging, astronomical observation, scientific research, military industry and other precision instruments.
