Diesel Gold processing washing plant Double Layer Trommel Gold Recovery machine

Product Overview

Description

SPECIFICATIONS OF GOLD WASHING MACHINE
Model	MGT50	MGT100	MGT200
Parameters
Size /mm	7000*2000*3000	8300*2400*4700	9800*3000*5175
Capacity	50-80 tph	100-150 tph	200-300 tph
Power	50 kw	120 kw	150 kw
Feeder Hopper /mm	2000*2200	3000*2200	3800*3000
Clay Scrubber /mm	φ1000*2000	φ1200*3000	φ1500*3000
Trommel Screen /mm	φ1200*3000	φ1500*3500	φ1800*4000
Sluice Box	2 sets	3 sets	4 sets
Water Supply /m³	120 m³	240 m³	370 m³
Wheels	6 wheels	10 wheels	10 wheels
Recovery Rate	98%	98%	98%





Pre-Sales Service	Afer-Sales Service
Receiving clients inquiry Studying clients mining conditions Introducing our machinery Propose the most suitable solution	Design outlet with 3D drawing photo Producing according to the design Inspection and testing before delivery Engineers installation and training service

Q1. Are you factory?
A: Yes , established in 2002 , over 17 years factory.



Q2. How big are you?
A: In tolal 4 work shops , 12,000 m , office 2000 m , 65 workers.



Q3. What equipment do you build?
A: Specialized in allnuial / placer gold / diamond mining equipment.



Q4: Whats the capacity of the gold /diamond mining equipment?
A: From 5TPH to 450 TPH.



Q5: What brand engine / diesel generator do you use?
A: Cummins , Weichai , Yuchai , etc , or as required.
