2 tonh 15 th City Gas Light Oil Diesel lpg hfo Fired Fire Tube Steam Boiler Price
- Category: Boilers & Parts >>>
- Supplier: Kaifeng Xinli Boiler Equipment Co. Ltd.
Share on (1600512487313):
Product Overview
Description
2 tonh lpg 15 th City Gas Light Oil Diesel lpg hfo Fired Fire Tube Steam Boiler Price
WNS Oil Fired Steam Boiler offered by us are designed and manufactured to deliver optimum functionality in the given environment. Backed by cutting edge features and special designs, these fully automatic systems provide complete ease of operations and maintenance. Package Type, Fully Automatic, three pass & water tube design electric steam boilers. These industrial steam boilers are designed to efficiently meet the demands of instantaneous steam. For achieving perfect combustion, it includes precisely designed smoke passages & combustion chambers.
Product Description
1.Model:WNS
2.Structure:horizontal fire tube, wet back, three pass
3.Steam Capacity:1-20ton/hour
4.Steam Pressure:1.0Mpa(10bar),1.25Mpa(13bar),1.6Mpa(16bar),2.5Mpa(25bar)
5.Steam Temperature:184 °c,194°c, 204°c,226°c(As long as the steam temperature you need is lower than 226°c, we can do it).
6.Fuel:heavy oil, light oil, natural gas, city gas, lpg,lng,etc
7.Application: textile mill, food, beer and brewery factory,chemical industry, garment factory, printing mill, paper masking industry,milk pasteurization, pharmaceutical industry etc.
Technical Parameters
| Model | Rated | Rated | Rated | Thermal | Fuel Consumption | Equipment Power | Weight | ||
Capacity (t/h) | Pressure (Mpa) | Temperature (C) | Efficiency (%) | Light oil (Kg/h) | Natural gas (Nm³/h) | Burn light oil | Burn gas | (t) | |
| WNS1 | 1 | 0.7/1.0/1.25 | 170/184/194 | >90 | 45-100 | 18-100 | 1.5 | 1.5 | 4 |
| WNS1.5 | 1.5 | >90.2 | 101.73 | 123.47 | 2.2 | 1.5 | 5 | ||
| WNS2 | 2 | 1.0/1.25/1.6 | 184/194/204 | >90.2 | 137.09 | 165.97 | 2.2 | 3 | 8 |
| WNS3 | 3 | >91 | 205.75 | 249.6 | 7.5 | 7.5 | 9 | ||
| WNS4 | 4 | >91 | 272.3 | 329.5 | 9 | 7.5 | 13 | ||
| WNS5 | 5 | >91.5 | 134-402 | 80-500 | 17.2 | 15 | 15 | ||
| WNS6 | 6 | >91.5 | 134-402 | 80-500 | 15 | 15 | 17 | ||
| WN8 | 8 | 1.25/1.6/2.5 | 194/204/225 | >91.6 | 523.4 | 631.5 | 26 | 22 | 21 |
| WNS10 | 10 | >91.6 | 212-890 | 150-1085 | 26 | 22 | 22 | ||
| WNS12 | 12 | >91.8 | 915.5 | 1090 | 26 | 22 | 27 | ||
| WNS15 | 15 | >91.8 | 931.5 | 1094.4 | / | / | 34 | ||
| WNS20 | 20 | >92 | 1380.33 | 1598.44 | / | / | 45 | ||
| Note: Parameter is for reference only, we can design the boilers based on customers’ needs. | |||||||||
Popular Boiler
Projects Case
Company Information
Customer Visiting
FAQ
Q1: How to get the best price quickly?
1) Please offer the boiler capacity & pressure you need, and the fuel you plan to use, then we could offer the suitable boiler model.
2) Please provide your name, email address, WhatsApp/WeChat/Skype, and company name, then we will send the best price and boiler details immediately.
Q2: How to ensure the boiler quality?
(1)Strength calculation report for applied materials information;
(2)100%NDT(non-destructive inspection) report of steel plate, tube and welding rod;
(3)100% X-ray inspection(welding seam): ensure the quality of entire boiler;
(4)Hydrostatic test: ensure the standard working pressure and safety;
(5)Third-party inspection report: Henan Boiler Inspection Institute;
(6)Passed ISO:9001,CE, SGS and Intertek certificate.
Q3: What about the installation and Commissioning?
After you receive the boiler, we will guide you to make some preparation for installation, and our experts will offer overseas installation service if you need, and fly to the installation site within 72 hours.
Q4:What is the using life of your boiler?
Normally the boiler is designed for 15 years life span, but with correct operation and well maintenance, the boiler operation life will be longer.
Q5: After Sales Service
1) Guarantee Period:12 months from the date of trial run finish, but not to exceed 18 months from date on which the goods leave factory.
2) If any parts (excluding easily damaging parts) are found defective in quality in the first year, we will replace free-of-cost.
