industrial touch monitor 15.6' monitor touch screen monitors
- Category: >>>
- Supplier: Markhub Smartech (Suzhou) Co. Ltd.
Share on (1600513123394):
Product Overview
Description
Product Description
With an iTAYFT touch screen monitor, it's possible to operate the screen and apps with your finger. That's useful for giving a presentation, having a customer look up a product in your self-service warehouse, or for a cash register system, for example.
Monitors with a touchscreen are also useful at home or at the office. Scroll through a web page with your fingers or zoom in on a photo. With a touchscreen, you control your monitor just like a tablet or a smartphone. There are touchscreen monitors available that can be adjusted in height. This way, you place the screen at a comfortable working height and your fingers can easily reach it. Touchscreens come in different sizes. The larger the touchscreen monitor, the more space to open multiple apps or tabs next to each other.
Technical Datasheet
LCD | ||||
Size | 15.6" TFT LCD | |||
Maximum Resolution | 1366 X 768 | |||
Contrast Ratio | 500:1 | |||
Brightness (Backlight Type) | 400 nits (No Touch), 360 nits (Projected Capacitive) | |||
View Angle | H:170˚, V:160˚ | |||
Touch | ||||
Touch Screen | Projected Capacitive | |||
Touch Points | 10 | |||
Touch Screen Interface | USB-HID (Type B) | |||
External Ports | ||||
Serial Port | - | |||
USB Port | 1 x USB 2.0 (Type B) for Touch Interface (USB-HID) | |||
Video Port | 1 x VGA | |||
Audio Port | - | |||
Power Input | 1 x 2.1 mm 12V DC Jack | |||
AIO | ||||
Power Supply | 50 W (12V / 4.16A) External Power Adaptor | |||
Speaker | NA | |||
Housing Color | Black | |||
Construction | Glass, SECC Metal | |||
Compliance | IP54 Compliant Front Side, IPX1 | |||
Dimensions (W x H x D) mm | 381.0 x 285.3 x 202.0 mm (With Stand), 381.0 x 230.3 x 46.0 mm (Without Stand) | |||
Net Weight (kg) | 4.3 kg | |||
Gross Weight (kg) | 6.6 kg | |||
Carton (W x H x D) mm | 365.0 x 455.0 x 290.0 mm | |||
VESA | 100 x 100 mm | |||
Environment Requirement | ||||
Operating Temperature | 0°C ~ 40°C, 20% ~ 80% RH. Non-Condensing | |||
Storage Temperature | -20°C ~ 60°C, 10% ~ 90% RH. Non-Condensing | |||
Applications
Industrial field,
Retail, Signal signage,
Medical field,
Financial,
Check-in, etc.
Company Profile
MARKHUB SMARTECH CO., LTD. is a branch of SINOTECTRONICS INC., concentrating on serving SNT-IPD product R+D and manufacturing.
With strong background of professional touch technologies and Display solutions, we are dedicating to offer to global market with our standard quality products as well as customized products. Markhub products are exported to more than 40 countries and regions globally via Sinotectronics, as the business grow steadily, we are happy to introduce our own branded products with unique design, like iTAYFT branded for our touch monitor series, and MIRROAWILLOV branded for our Mirror series products, moreover, our products are widely used in Retail, Signage, Gaming Machine, ATM/VTM, Education and Meeting, etc.
We would like to grow together with you and provide you more and more excellent products for serving the market, let’s join hand together, touch the world!
