Carbon free technology PEM Hydrogen Generation System Carbon neutral fuel generating station
- Category: >>>
- Supplier: Beijing Day-Pro Technology Co. Ltd.
Share on (1600513365400):
Product Overview
Description
Product Description
Specification
Tical parameters Description | Parameter |
Model No | CSDJ -QLS-H6 |
Output Flow (m³/h) (at 25℃, 1013hPa) | 6Nm3 |
Quantity of Cells (set) | 1 |
Ambient Temperature | 5-30℃ |
Water Requirement(Pure water) | Resistivity >1OMQ/cm (25-50 ℃ |
Water Tank Volume | 50L(stainless steel tank) |
Max Water Consumption(L/Hr) | 5 |
H2 outlet pipe size | 1/4 inch Or φ4 |
Output pressure | 0.02-3MPa |
Fluctuation rate of output pressure | <0.2% |
H2 Purity | >99.999% |
Dew Point | -65℃ |
Input power voltage | 380V, three phases |
Longevity: | 30000H |
Input power | <36KW |
Dimension of Main Machine(L*W*H) (mm) | 1600 ×1100×1750mm |
Gross Weight | 600 kg |
Packing | Wooden Case |
Features and Benefits
(1) PEM/SPE technology, raw material is only pure water (without adding alkali) to produce hydrogen
(2)High hydrogen purity, >99.999%
(3) Low Cell voltage, no corrosion, low maintenance cost
(4) Small electrolytic current, large hydrogen output, voltage increasing quickly (3 to 5 minutes).
(5) Perfect and reliable automatic control of hydrogen generation
(6) High electrolysis efficiency, less power consumption .
(7) Excellent seal performance.
(8) Overall safety protection including:
1. Pressure Transmitter Alarm
2. Hydrogen Overpressure Alarm
3. Hydrogen Permeation Alarm
4. Hydrogen Leak Alarm
5. Water Ponding Alarm
6. Surplus Water Alarm
7. Water Lack Alarm
8. Oxygen Permeation Alarm
9. Water Overheat Alarm
10. Water Quality Alarm
(2)High hydrogen purity, >99.999%
(3) Low Cell voltage, no corrosion, low maintenance cost
(4) Small electrolytic current, large hydrogen output, voltage increasing quickly (3 to 5 minutes).
(5) Perfect and reliable automatic control of hydrogen generation
(6) High electrolysis efficiency, less power consumption .
(7) Excellent seal performance.
(8) Overall safety protection including:
1. Pressure Transmitter Alarm
2. Hydrogen Overpressure Alarm
3. Hydrogen Permeation Alarm
4. Hydrogen Leak Alarm
5. Water Ponding Alarm
6. Surplus Water Alarm
7. Water Lack Alarm
8. Oxygen Permeation Alarm
9. Water Overheat Alarm
10. Water Quality Alarm
Technical Highlights
* Highly reliable
* Integrated All-in-design, Supper high system power density.
* Precise control strategy and efficient thermal management system design to ensure the safe and sustainable operation of the system under all working conditions
* Integrated THD monitoring to realize online diagnosis of system working condition
* Software and hardware are developed according to functional safety design process to ensure high security of the system
* The system strictly follows the V model development process and completely covers the design requirements and test
verification requirements
* Integrated All-in-design, Supper high system power density.
* Precise control strategy and efficient thermal management system design to ensure the safe and sustainable operation of the system under all working conditions
* Integrated THD monitoring to realize online diagnosis of system working condition
* Software and hardware are developed according to functional safety design process to ensure high security of the system
* The system strictly follows the V model development process and completely covers the design requirements and test
verification requirements
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Established in 2013, Beijing Day-Pro Technology Co., Ltd.is a leading professional company in gas generating equipment.
Our principle is to pursue high quality and excellent performance. Our advantages are as the following:
We have very strong technical team of 150 staff.
We have our own factory to design and produce according to your requirements. We have strong team to manufacture and service.
We provide customized and complete solution.
We focus on long-term business cooperation with our clients!
Our principle is to pursue high quality and excellent performance. Our advantages are as the following:
We have very strong technical team of 150 staff.
We have our own factory to design and produce according to your requirements. We have strong team to manufacture and service.
We provide customized and complete solution.
We focus on long-term business cooperation with our clients!
FAQ
1. who are we?
We are based in Beijing, China, start from 2013,sell to Domestic Market(45.00%),North America(10.00%),Southeast
Asia(10.00%),Western Europe(10.00%),Mid East(5.00%),South Asia(5.00%),Northern Europe(5.00%),Eastern Europe(5.00%),Eastern
Asia(5.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Oxygen Concentrator,Hydrogen Generator,Nitrogen Generator,Air Generator,Hydrogen Breath
4. why should you buy from us not from other suppliers?
We have professional staff for products and after-sales service. Our strong R&D team promises superb product quality. We provide
24h*7days online service. Welcome your inquiry!
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Western Union,Cash;
Language Spoken:English,Chinese
We are based in Beijing, China, start from 2013,sell to Domestic Market(45.00%),North America(10.00%),Southeast
Asia(10.00%),Western Europe(10.00%),Mid East(5.00%),South Asia(5.00%),Northern Europe(5.00%),Eastern Europe(5.00%),Eastern
Asia(5.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Oxygen Concentrator,Hydrogen Generator,Nitrogen Generator,Air Generator,Hydrogen Breath
4. why should you buy from us not from other suppliers?
We have professional staff for products and after-sales service. Our strong R&D team promises superb product quality. We provide
24h*7days online service. Welcome your inquiry!
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Western Union,Cash;
Language Spoken:English,Chinese
