Polycarbonate Clear Roof Double Wall Sheeting Standard Sizes
US $1.17-$10.78
polycarbonate hollow transparent corrugated roofing sheet sizes
- Category: >>>
- Supplier: Zhejiang Huashuaite New Material Technology Co. Ltd.
Share on (1600515363114):
Product Overview
Description
Brief introduction of polycarbonate sheet :
1. Thickness: 3.8mm to 30mm
2. 100% virgin Bayer/Lexan material
3. UV protection(One side or two sides)
4. 10-year warranty
5. Certificate :ISO9001:2008, ROHS , SGS
6. High quality & competitive price
7. Color: clear, green, blue , light blue , brown , opal , red , yellow .
8. Delivery time :7-10days for 1*40FCL .
9. Payment : T/T , LC , CASH .
1. Thickness: 3.8mm to 30mm
2. 100% virgin Bayer/Lexan material
3. UV protection(One side or two sides)
4. 10-year warranty
5. Certificate :ISO9001:2008, ROHS , SGS
6. High quality & competitive price
7. Color: clear, green, blue , light blue , brown , opal , red , yellow .
8. Delivery time :7-10days for 1*40FCL .
9. Payment : T/T , LC , CASH .
Features of polycarbonate sheet :
1. very high impact strength
2. Good light transmission
3. good weather resistance and UV protection
4. high heat insulation
5. Simply processed and installed
6. UV protection layer: 50um
7. soften temperature : 148°C
8. continuous use temperature :-40 ~120°C'
9. elastle stress :2400MPa(1mm/rain.ISO 527)
10. tensile stress :63MPa(at yeild 50mm/min.ISO 527)
11. tensile strain:6%(at yeild 50mm/min.ISO 527)
12. nominal tensile strain: >50%(at break 50mm/min.ISO 527)
1. very high impact strength
2. Good light transmission
3. good weather resistance and UV protection
4. high heat insulation
5. Simply processed and installed
6. UV protection layer: 50um
7. soften temperature : 148°C
8. continuous use temperature :-40 ~120°C'
9. elastle stress :2400MPa(1mm/rain.ISO 527)
10. tensile stress :63MPa(at yeild 50mm/min.ISO 527)
11. tensile strain:6%(at yeild 50mm/min.ISO 527)
12. nominal tensile strain: >50%(at break 50mm/min.ISO 527)
Application of polycarbonate sheet:
1) Building skylights
2) Indoor partition, folding screen
3) Furniture
4) Bathroom
5) Natatorium coverings
1) Building skylights
2) Indoor partition, folding screen
3) Furniture
4) Bathroom
5) Natatorium coverings
Thickness(mm) | Structure | Weight(g/sqm) | Min.Bend Radius(mm) | K value (W/M2K) |
4 | 2-layer | 850 | 700 | 4.1 |
5 | 1000 | 875 | 3.8 | |
6 | 1300 | 1050 | 3.6 | |
8 | 1500 | 1400 | 3.3 | |
10 | 1700 | 1750 | 3 | |
6 | 3-layer | 1400 | 1050 | 3.4 |
8 | 1600 | 1400 | 3.2 | |
10 | 2000 | 1750 | 2.7 | |
12 | 2100 | 2100 | 2.6 | |
14 | 2400 | 2450 | 2.4 |
Q1. Could I get samples before place an order?
A: Yes, We always have many kinds of thickness samples on stock, you can get them free for charge.
Q2. What about the lead time?
A: Mass production time needs 2-4 weeks according to your order quantity.
Q3. May I have your catalog and price list?
A: Of course, Please have a detailed looking and choose the interested models in our site. Then contact us,
we can offer your details as your request.
Q4. What’s your advantage?
A: (1) 20 years Production experience
(2) High quality with competitive price
(3) 10 years quality guaranteed
(4) Fast response and professional suggestion on all inquiries
(5) Welcome customized sizes
(6) Certified by SGS, ISO
Q5. What happens if my products are damaged?
A: If the products are damaged during transportation from China to your destination, please take pictures and
send the details to us, we will take full responsibility.
A: Yes, We always have many kinds of thickness samples on stock, you can get them free for charge.
Q2. What about the lead time?
A: Mass production time needs 2-4 weeks according to your order quantity.
Q3. May I have your catalog and price list?
A: Of course, Please have a detailed looking and choose the interested models in our site. Then contact us,
we can offer your details as your request.
Q4. What’s your advantage?
A: (1) 20 years Production experience
(2) High quality with competitive price
(3) 10 years quality guaranteed
(4) Fast response and professional suggestion on all inquiries
(5) Welcome customized sizes
(6) Certified by SGS, ISO
Q5. What happens if my products are damaged?
A: If the products are damaged during transportation from China to your destination, please take pictures and
send the details to us, we will take full responsibility.
