Product Overview
Description
ODM Services Available Aluminum Die Casting Component Parts For Medical Device and Dental Products
Product Description
- We offer precision aluminum die casting component parts to medical device & equipment manufacturers. We provide one stop solutions on fabrication services and fully integrated operations in mold design & developed, aluminum die casting, machining, anodizing, powder coating, assembly and technical services.
- Aluminum Die Casting Process Is A Metal Casting Process That Is Characterized By Forcing Molten Metal Under High Pressure Into A Mold Cavity. The Mold Cavity Is Created Using Two Hardened Tool Steel Dies Which Have Been Machined Into Shape And Work Similarly To An Injection Mold During The Process;
aluminum die casting component parts Applications in the medical industry:
Compliance with RoHS and REACH regulations;
Very high sanitation levels;
Extremely Lightweight;
The optimum strength-to-weight ratios;
And it doesn`t rust, which is critical with items requiring frequent sterilization;
A passivation layer that protects aluminum even if it becomes nicked or scratched;
Machinability / Recyclability / Esthetic Finishes;
Cheaper alternative to some other high-performance materials;
Economically;
Excellent thermal conductivity;
Adherence to tight tolerances, EMI shielding, High dimensional stability;
Ease of assembly with mating components;
- The Essence Of aluminum die casting component parts Is Under The Action Of High Pressure, So That Liquid Or Semi-Solid Liquid Metal And High Speed Filling Into The Die-Casting Mold Cavity, And Under Pressure In The Molding And Cooling Solidification Obtained Die Casting (Die-Casting Machine Parts) Forming Process. This Shows That In The High-Pressure And High-Speed Die-Casting Mold Cavity Filled With Two Major Characteristics Of Die-Casting Process;
- aluminum die casting component parts HS Code: 761699;
- Harmonized Tariff Schedule (HTS) on aluminum die casting component parts : 7616995160;
- Die Cast Aluminum Alloys Available: ADC12, A380, AlSi9Cu3;
Medical Post-Processing Capabilities:
Surface treatment of aluminum die casting component parts help make these items even more scratch and wear-resistant and more attractive which never hurts when it comes to speeding up patient healing
Powder Coating
Anodizing
Heat Treatment
Passivation
Electroplating.
Technical Information on Aluminum Die Casting
| Siz Range | Not normally over 2.7feet square |
| Parts Weight | 0.01pounds to 14 pounds |
| Setup Cost | New die casting tooling is free |
| Tolerances | 0.02inch,add0.01inch to 0.015inch across parting line up to part size |
| Die Casting Finish | 32~63 RMS |
| Minium Draft | normally 1° |
| Billet | normally 0.04inch |
| Normal Minimum Section Thickness | 0.060inch for small parts; 0.090inch for medium parts |
| Ordering Quantity | For first trial order: not less than 100pcs; Usually 1,000pcs or more. |
| Normal Leadtime | Tooling: 4~12 weeks update part size; Samples: one week if no finish and CNC machining required; Production:2~3weeks |
What we make
ODM Services Available Aluminum Die Casting Component Parts For Medical Device and Dental Products
| What kind of Parts we can make? | |
| Parts | OEM/ODM Die Casting Parts;Tooling/Mould |
| Casting Material | Diecast Aluminum Alloy:A380,A383,ADC12,AlSi9Cu3,AlSi12Cu,etc |
| Diecast Zinc Alloy:Zamack 3,Zamack 5,etc | |
| Tooling/Mould Material | Die Steel: H13,SKD61,3CR2W8V,8407,etc. |
| Tooling/Mould Standard | DME,HASCO,LKM,CUMSA,MISUMI,DAIDO |
| Casting Product Weight | From 0.03kg to 10kg |
| Machining Tolerance | 0.005mm~0.01mm |
| Use for | • Automobile • Motor • LED Lighting |
| • AV Device • Machinery • Telecommunication Apparatus | |
| • Furniture • Medical Instrument • Custom | |
Aluminum Die Casting Services Finish Available
Other CustomizedFinish/Surface treatment is welcome.
Why Choose Us?
- OEM Quality
- Competitive Priced Parts
- Flexible Volume
- Delivered On Time
- One-Stop Solution
- Trust Assurance Support.
Our Company
ODM Services Available Aluminum Die Casting Component Parts For Medical Device and Dental Products
Company
- Established in March,23th,2004
- Located in Beilun ,Ningbo which is one of the biggest port
- Occupied area of 70,000 square feet
- 105 Employees & 6 Engineers
- Products main export to Europe and America
Tooling Workshop
The quality of casting tooling, trimming tooling and machining fixture is the key point to keep the quality finished parts.
We offer design services capable of taking an idea or reviewing the existing part design and creating this design to castability
and machining availability.
Die Casting Workshop
Diecasting Machines: 280T,400T,500T,800T.
Equipped with automatic lading machine,sprayer,oil cooling and water cooling system.
Machining Workshop
The completely machining machines can fully satisfy all machining requirements for castings.
We can offer a complete in-house machining for die casting parts including boring,CNC,drilling,
sanding,tapping,turning,broaching,burnishing,lapping,reaming,etc.
Surface Treatment workshop
Equipped machines for sand blasting, shot blasting,Vibration,Paiting,Powder Coating,etc
Inspection laboratory
Equipped:Coordinate Measuring Machine (CMM),Spectrograph ,Tensile Testing,X-Ray Detecting.etc
Quality Control
As an IATF 16949 certified high pressure die casting manufacturer, we offer quality products and value-added services. The quality management system encompasses all of our manufacturing and customer service programs.
FAQ
1. Is Ningbo Jiawei a trade company or manufacturer?
Ningbo Jiawei is an aluminum die casting and CNC machining manufacturer. Our facility was located in Ningbo, China. It only takes 10minutes from our facility to Ningbo seaport. We can be your China Aluminum die casting and CNC machining supplier to easily and speedy export these aluminum die casting parts to all over world.
2. What is Ningbo Jiawei`s core competitive power?
Ningbo Jiawei is a one-stop aluminum die casting solution provider. We offer tooling, die casting, machining, shotblasting in-house, and out-source other surface treatments from our contracted suppliers. The turnkey solution is our core competency compared with other die casters.
3.Why should we purchase our parts from Ningbo Jiawei?
As a professional aluminum die casting manufacturer, Ningbo Jiawei has these advantages to push you take into consideration to us as you sourcing aluminum die casting supplier in China.
- The rich experience engineering teams can provide the professional technical support, manufacturing evaluation, improved suggestions on your original design from cost-effective way during casting and manufacturing processes;
- lOur fast service and promptly feedback can save you lead time;
- One-stop solution service and turnkey service can help you reduce your workload and speed up your project time and bring you a reasonable cost, quality parts and timely delivery.
4. What industries does Ningbo Jiawei serve?
The industries classification on Ningbo Jiawei Served:
For NAICS (North American Industry Classification) Code
3315 Foundries, Manufacturing
331523 Nonferrous Metal Die-Casting Foundries
Aluminum die-casting foundries
Aluminum die-castings, unfinished, manufacturing
Foundries, die-casting, nonferrous metals
3343 Audio and Video Equipment Manufacturing
334310 Audio and Video Equipment Manufacturing
3351 Electric Lighting Equipment Manufacturing
335122 Commercial, Industrial, and Institutional Electric Lighting Fixture manufacturing
3363 Motor Vehicle Parts Manufacturing
336310 Motor Vehicle Gasoline Engine and Engine Parts Manufacturing
336320 Moto Vehicle Electrical and Electric Equipment Manufacturing
336330 Motor Vehicle Steering and Suspension Components (except Spring) Manufacturing
336340 Motor Vehicle Brake System Manufacturing
336390 Other Motor Vehicle Parts Manufacturing
3369 Other Transportation Equipment Manufacturing
336991 Motorcycle, Bicycle, and Parts Manufacturing
336999 All Other Transportation Equipment Manufacturing
5. Does Ningbo Jiawei have any sort of quality certification?
Ningbo Jiawei has the quality certification of IATF16949.
6. Can Ningbo Jiawei sign our NDA before we provide project information?
Yes, we sign the NDA with all customers and we will always pay more attentions on the protection of customer`s intellectual property and information confidential.
7. What die casting alloys does Ningbo Jiawei usually use for die casting components?
Aluminum die casting: ADC12 , A380, A360, AlSi12, AlSi9Cu3
Zinc die casting: zamak 3 & zamak
8. What is Ningbo Jiawei lead time for tooling/mould/mold?
That will be subject to the mold size. Typical, lower than 800tonnage die casting machine, 30~45days; More than 800 tonnage die casting machine, 50~70days. If you have the urgent demand, please talk with us and we will expedite as we can
9. What`s Ningbo Jiawei product types?
Ningbo Jiawei can provide die casting tooling, precision CNC machining and aluminum die casting products.
10. What kind of surface treatment can Ningbo Jiawei provide?
We have cleaning and shot blasting in-house. Worked with contracted partner, we can offer various surface treatments such as painting, powder coating, chrome-plating, anodizing.
