ET011 Temperature control mechanical mini thermostat 0 to 60 degrees manual reset
- Category: >>>
- Supplier: Xiamen Pope Electric Company Limited
Share on (1600516948796):
Product Overview
Description
ET011 Temperature control mechanical mini thermostat 0 to 60 degrees manual reset
| Switch temperature difference |
| ||
| Contact Type |
| ||
| Permissible air velocity | 15m/sec | ||
| Max switch capaticy | 250VAC, 10 (2) A | ||
| Min. switching capacity | 120VAC, 15 (2) A | ||
| Service life | > 100,000 cycles | ||
| Connection | 2-pole terminal, clamping torque 0.5Nm max.: rigid wire 2.5mm², stranded wire (with wire end ferrule) 1.5mm² | ||
| Operating/Storage temperature | -45 to +80°C (-49 to +176°F) | ||
| Protection Type | IP 20 |
product description:
